SYSTEM SETTING
According to the system of the TV to be connected, set the sys
tem of the unit to make it match the TV type
1. If the system of the TV is PAL, select the menu item in the
Setup Menu as :
PREFERENCE SETUP >> TV DISPLAY >> PAL
2. If the system of the TV is NTSC, select the menu item in the
Setup Menu as :
PREFERENCE SETUP >> TV DISPLAY >> NTSC
3. If the TV is multi system, select the menu item in the Setup
Menu as:
PREFERENCE SETUP >> TV DISPLAY >>AUTO
V MODE SETTING
According to the video mode of TV set, push "V MODE" key to
setup its video mode that matching to the video mode of TV set.
OSD
When playing DVD discs, the TV screen shows the information as :
First pressing "DISPLAY" key : Title Elapsed
TT ** / ** CH ** / ** **: ** : **
Second pressing "DISPLAY" key: Title Remain
TT** / ** CH ** / ** **: ** : **
Third pressing "DISPLAY" key: Chapter Elapsed
TT** / ** CH ** / ** **: ** : **
Forth pressing "DISPLAY" key: Chapter Remain
TT ** / ** CH ** / ** **: ** : **
Fifthly pressing "DISPLAY" key: Display Off
VOLUME CONTROL
Push "VOLUME" button on the TV or remote control.
The screen shows:
VOL 20
Push "+" button or " "button to raise or lower the volume.
DVD MENU PLAY
Some DVD discs have title menus and root menus. Push
"TITLE/PBC" button , the screen shows the title menu. Push
"MENU" button, the screen shows the root menu. Push "UP"
button or "DOWN" button, the screen shows the last page or
next page. Push number button to select directly.
SELECT WITH NUMBER BUTTON
Load a disc, Push number button to select tracks after the unit
finishes reading the disc.
1. If the track number is less than 10, just push a button among
1 10.
2. If the track number is over 10, push 10+ once on the remote
control and a button among 1 10.
SELECT LANGUAGE
You can choose the language according to your choice when
playing multi language DVD.
Note:
1. Different disc has different languages
2. You can push "AUDIO" button to choose the language you
want when you play multi language VCD discs.
SELECT CHANNELS
You may select channel when it plays.
Push "CHANNEL" button, the screen show alternately and
select the desired audio channel:
Mono Left
Mono Right
Mix Mono
Stereo
STOP PLAY
It will stop when you push "STOP" key, and it will play again if
you push "PLAY" key.
PAUSE PLAY
Push "PAUSE" key, it will stop playing, and it will play again if you
push "PLAY" key.
FAST PLAY
When playing disc, you may play it forward fast or reverse it fast
to find what you need.
1. Push
to play forward fast. Each time you push the button,
the screen shows orderly.
1. 2X
2. 4X
3. 8X
4. 16X
5. 32X
6.
2. Push to reverse the disc fast. Each time you push the but
ton, the screen shows orderly:
1. 2X
2. 4X
3. 8X
4. 16X
5. 32X
6.
SLOW PLAY
Enjoy slow motions by the following steps.
Push "SLOW" button to play slowly.
1. 1/2
2. 1/4
3. 1/8
4. 1/16
5.
ENGLISH
7
