REFERENCE DRAWING FOR FRONT PANEL
REFERENCE DRAWING FOR CONNECTION (BACK SIDE)
INSTRUCTION CHART AND SPECIFICATION
ENGLISH
4
1. STAND/BY ON KEY
2. MIC JACK
3. MIC LEVEL JACK
4. REMOTE SENSOR
5. OPEN/CLOSE KEY
6. PLAY KEY 7. PAUSE KEY
8. STOP KEY
9. PREV KEY
10. NEXT KEY
11. DISPLAY WINDOW
1. DIGITAL AUDIO OPTICAL FIBER OUTPUT
2. SUBWOOFER OUTPUT
3. RIGHT SURROUND OUTPUT
4. MAIN RIGHT OUTPUT
5. DIGITAL AUDIO COAXIAL OUTPUT
6. S VIDEO OUTPUT
7. Cb/Pb SIGNAL OF COMPONENT VIDEO OUT 8. SCART OUTPUT
9. Cr/Pr SIGNAL OF COMPONENT VIDEO OUT
10. Y SIGNAL OF COMPONENT VIDEO OUT
11. VIDEO OUTPUT
12. MAIN LEFT OUTPUT
13. LEFT SURROUND OUTPUT
14. CENTER OUTPUT
