Turbo Steam Ironing
Vertical steam ironing:
Auto-shut off function
Anti-drip system:
Turbo Steam feature provides additional steam for removing stubborn creases.
1. Set the "adjustable steam knob" to "
"position, and then fill the water tank
with clean tap water refer to above filling instruction.
2. Connect the appliance to a suitable socket outlet, set the temperature control
button to "MAX" position. The power indicator light will blink, which indicate
that the unit being heated up, When the power indicator light change to
illuminate steadily, the required temperature is reached.
3. Press the turbo steam button two or three times in quick succession to obtain
more powerful turbo steam.
4. It is normal that a small amount of water may be ejected from the soleplate
when pressing turbo steam button so frequently that temperature of soleplate
will be decreased accordingly. It is supposed to stop pressing turbo steam
button, and allow it to heat up again.
5. Before storing, allow the unit completely cool down.
Caution: when using turbo steam ironing, turn adjustable steam knob to "
"
position.
Follow the steam ironing process, and then hold the
iron in vertical position between 15cm away from the
hanged fabrics.(Fig 6).Press the steam button, this will
create vertical steam. This feature is especially used
for removing creases from hanging clothes and
curtains.
Never perform steam ironing directly on person.
Note: Power indicator light blinks quickly, which
indicate the temperature of soleplate is too high;
slowly blink showing low temperature.
VS-656: The appliance will automatically shut off if it has been successively used
for more than 60 minutes, and all illuminate light will go out. To continue ironing,
only press the temperature control button again.
VS-656-M: When the iron is stationary in horizontal position for about 30 seconds
or in vertical position for about 8 minutes, the unit will auto shut off. All indicator
light turn off. Press down the reset button or allow the iron move front to back, it will
be react to original fabric setting again.
This appliance has a safety mechanical protection which can protect water drip
from the soleplate when the temperature of steam chamber is so low that it cannot
provide steam..
Anti-calc system:
Maintenance:
1. The anti-calc box is designed to purify hard water and
reduce the build-up of limescale which occurs during steam
ironing, this will prolong the working life of your iron.
2. The anti-calc box should be replaced with a new one after
two months, in case of using one time each day, and you
can contact with manufacturer or agency for purchasing a
new one).
3. To replace the anti-calc box, take it out of the water-filling
hole, and then replace with a new one. (Fig.7)
After several use of your iron, a little amount of limescale will be built up in the
steam chamber and steam outlet, follow up below self-cleaning process, it will be
well removed.
1. Set the adjustable steam knob to" "position.
2. Fill water tank with water to max filling line.
3. Place the iron on the ironing rest, and put a
sink under the ironing rest to prepare for
pouring water and ejecting steam.
4. Set temperature control button to "MAX"
position.
5. Plug the unit into the main socket.
6. Allow the iron to heat up for 2 minutes
7. Disconnect the iron from main socket.
8. Hold the iron horizontally over the sink.
9. Push the self-cleaning button. (Fig.8)
10. Boiling water and steam will emit from the outlet of the soleplate and wash
away the impurities and scale.
11. Move the iron backwards and forwards while this happens. Go on letting
steam and water escape until the water tank is virtually empty.
12. Set the adjustable steam knob to " " position.
13. Insert the iron into main socket again.
14. Set the temperature control button to "MAX" position, Let the iron heat up
again. The remainder of the water inside the steam chamber will now
vaporize.
15. Unplug from power supply and allow soleplate to cool down and wipe it clean
with a soft damp cloth.
Note: Never use scouring pads, abrasive or harsh cleaners as this may scratch
the surface.
Fig.6
Fig.7
Fig.8
