Fill Water Tank
Make sure that the iron is unplugged from main socket
before filling water into the water tank.
1. Set the adjustable steam knob to " " position (Fig.2)
2. Take anti-calc box out of the filling hole (Fig.3)
3. Using a cup, slowly pour tap water or distilled water
into the water tank as shown in Fig.4 .
Never to fill beyond the Max filling line.
4. Replace the anti-calc box into the filling hole as shown in Fig.5 .
5. Hold the iron in horizontal direction, and then move the iron from front to back
for about 30 seconds so that limescales in water can be purified by the ion
exchange resin in the anti-calc box.
fig.3 fig.4 fig.5
fig.2
Note:
VS-656
VS-656-M
Dry Ironing
Note:
1. For every first use, the appliance should be pre-heated for about 2 minutes.
2. During steam ironing, it is normal that steam is stopped for a short time. Which
may be caused by lower temperature of soleplate or so high steam rate that
the anti-drip system is automatically reacted.
3. When setting the temperature control button at ” ” or ” ” position, there are no
steam go out of the soleplate since the temperature of soleplate is so low that it
can not produce steam.
Allow the iron resting motionlessly on the solepate or on its heel, the unit will come
into auto shut off mode, please refere to the auto shut off function described
below.
1. Place the iron on a level, horizontal ironing board
2. Set the adjustable steam knob to " " position, and then fill the water tank with
clean tap water refer to above filling instruction.
3. Connect the appliance to suitable power socket, and then set temperature
control button to the desired position according to different fabrics. The power
indicator light will blink, which indicate that the unit being heated up, When the
power indicator light change to illuminate steadily, the required temperature is
reached. It is ready for dry ironing.
4. If water spray is necessary, press down the spray button two or three times in
quick succession, water can be sprayed evenly in the fabric.
5. After use, disconnect the appliance from main socket.
6. Before storing , allow the unit completely cool down.
When changing your temperature control button from high setting to
lower, it is proposed that not to start ironing immediately since there may be
any burns caused on your fabrics by high temperature. Please wait for the
indicater light illuminate steadily and then start ironing.
Note: When using distilled water, you can mix it with tap water in a
proportion of 50%
1. Place the iron on a level, horizontal ironing board
2. Set the adjustable steam knob to " " position, and then fill the water tank with
clean tap water refer to above filling instruction.
3. Connect the appliance to a suitable power socket, set the temperature control
button to "MAX" position. The power indicator light will blink, which indicate
that the unit is being heated up, When the power indicator light change to
illuminate steadily, the required temperature is reached. In this stage, it is
normal that a "pong" sound produced, it because that the steam switch
automatically turn on.
4. For every first use, press down the turbo steam button several times
continuously, and then press down the self-cleaning button for about 10
seconds to clean the steam chamber.
5. Set temperature control button to desired position according to different
fabrics, put the adjustable steam knob to " " position, and then steam will
come out from steam vents of soleplate. During steaming iron, it is normal that
the power indicator light cycle from blinking to illuminate steadily. It is because
the appliance automatically heat preservation.
6. After use, turn adjustable steam knob to " "position, disconnect the
appliance from power socket.
7. Before storing, allow the unit completely cool down.
Steam ironing
