P/5 P/6
Do not turn the pot while draining out the
water or using water output function
Do not touch the button for opening the
cover when moving the pot.
Please fill the water atleast the more than
the Minimum level required.
Otherwise it may dry the water and initiate
dry-boiling. This may cause the internal
water tank to turn and long time dry boiling
may damage the pot or even cause fire.
Do not place the pot close to the wall,
furniture or other electrical appliances.
Otherwise steam and heat may damage
the wall, furniture and electric, cause
color fading or distortion.
Ø If the soft power cord is damaged, please contact the authorized repair
office for repairing the wire.
Rated voltage 230V
Rated power 750W while boiling 35W when Keep warm
Rated Frequency 50Hz
Rated Capacity 2.5 L
DESCRIPTION AND PARTS
Method for opening the Lid cover Method for detaching the lid from the Air-Pot Method for attaching the lid cover to the Air-Pot
Press the park of the lid cover
open button to open the lid cover,
(if the lid cover button is installed with
hole, it can directly open the up cover). Press the disassemble button (mentioned
at the rear of the air-pot), hold and pull
the open cover button. Insert the metal rotating shaft of the
lid-cover into the slot of button.
1. Internal Tank
2. Water Output Nozzle
3. Single-Touch Cup Switch
4. Marks of Water Level
5. Water Level Gauge
6. Rotating Base
7. Air Pressure water output
8. Lid cover open button
9. Steam Outlet
10. Air pressure water output
lock/release
11. Place for Filling water
12. Indicator for “Max. Level”
of water
13. Coupling Unit
(Power cord socket)
14. Power Cord
