Operation
Insert/Eject disc
• Insert a disc into the disc slot with label
side up. The disc will be automatically loaded
into the unit. The first file in the root folder will
be played.
• Press EJECT button to eject the disc from
the slot. If the disc is not removed from the slot
within several seconds, it will be automatically
loaded into the slot again. When the disc is
ejected and removed, the unit will automatically
switch to another mode.
Inserting an SD/MMC card/USB device
Insert an SD/MMC memory card into the
card slot. Open the USB slot cover on the front
panel and insert a USB into the USB slot. Then
the playing mode will be changed into Card or
USB mode automatically. The first card/USB
device track playback will start.
When SD/MMC card and USB device are
both inserted, the playing mode will be changed
into the mode of the device inserted later.
DVD touch interface
When a DVD is played, touch the center
of the screen; the screen will show following
interface:
1 2 3
4 5 6 7 8 9 10 11
MENU
1. Disc type
2. Current playback title/chapter/track
number
3. Current playback time
4. PLAY/PAUSE button. Touch to start,
pause or resume playback.
5. STOP button. Touch to stop playback
6. button. Touch repeatedly to change
rewind speed.
7. button. Touch repeatedly to change
fast forward speed.
8. REPEAT button. Touch repeatedly to
select repeat playback mode.
9. SUBT button. Touch to select disc subtitle
language.
10. AUD button. Touch to select disc audio
language.
11. MENU button. Touch to go to the disc
root menu.
VCD touch interface
When a VCD is played, touch the center
of the screen; the screen will show following
interface:
1 2 3
4 5 6 7 8 9 10
1. Disc type
2. Current playback title/chapter/track
number and PBC status
3. Current playback time
4. PLAY/PAUSE button. Touch to start,
pause or resume playback.
5. STOP button. Touch to stop playback
6.
button. Touch repeatedly to change
rewind speed.
7. button. Touch repeatedly to change
fast forward speed.
8. REPEAT button. Touch repeatedly to
select repeat playback mode.
9. AUD button. Touch to select audio channel.
10. PBC button. Touch to switch BPC
function on or off.
