Operation Operation
AV in jack
AV jack is intended to receive audio and video
signals by connecting to external device.
Subwoofer
Connect a subwoofer to this unit using the
Subwoofer output of this unit. For subwoofer
operation an external amplifier is required.
Dual zone function
DUAL - dual zone function enabling user to
listen to radio or watch TV in the front zone,
and at the same time play audio or video from
disc, USB or memory card.
For Dual zone en external monitor with is
required having its own acoustic system and
possibility of volume adjustment.
Press and hold SEL button on the front panel
or press DUAL button on the RC to select
between C-DUAL (buttons perform operations
for the current mode of the front zone) or
D-DUAL (buttons perform DVD functions).
System setup
When you select SETTING mode or press
SETUP button on the RC, the menu will be
displayed, in which you can touch any item to
perform operations as follows:
1 2 3 4
5 6
1. Menu page list. Touch any page icon to go
to corresponding menu page.
2. Setting list. Touch a setting to select its
adjustment.
3. Adjustment buttons.
4. Option selection button. Touch to go to
option list for corresponding setting. Touch an
option to select it.
5. Subpage number.
6. Subpage selection button. Touch to switch
between suppages of each setting list.
You can also navigate in the menu by
pressing cursor buttons on the RC and confirm
your selection by pressing ENTER button on
the RC.
Sound page
• EQ: Select Flat, Classic, Pop, Rock or
User equalizer mode.
• Bass: Adjust the low-frequency level.
• Treble: Adjust the hogh-frequency level.
• Balance: Adjust the balance between left
and right channels.
• Fader: Adjust the balance between front
and left channels.
• Volume: Adjust the sound volume level.
• Beep: Select ALL (beep is heard at any
button pressing), 2ND (beep is heard when a
button is pressed and held) or OFF (no beep).
• Loud: Selecting loudness ON will
emphasize the low frequency output.
• Subwoofer: set the subwoofer on or off.
Display page
• Screen: Select 16:9, 4:3 or FULL screen
modes.
• Backlight: select LOW, MID or HIGH
display backlight level.
RDS and Radio page
• Stereo: Select ON (stereo reception mode)
or OFF (mono reception). When the received
stereo signal is weak, switch to mono mode to
improve the signal. The function is available
only in FM bands.
• Local: Select ON (only local station
reception) or OFF (local and distant station
reception). The function is available only in FM
bands.
• TA volume: Adjust level of TA volume.
• Retune: Long/Short. RETUNE refers to the
