6
23.Turbo brush (except CVC-7165)
24.Accessory bracket (except CVC-7100)
BEFORE USE
Vacuum cleaner assembly
Flexible hose connection
Insert plastic base of the flexible hose (3) in
the inlet hole (2) until it clicks.
For model CVC-7190: turn the hose (3)
right when it is pushed into the bottom, a click of
inserting sound may be heard.
Flexible hose disconnection
Press the hold-button (5) and pull out the hose.
For model CVC-7190: rotate the hose contra clockwise
and pull out it.
Application of nozzles and working parts
X By pressing the tube length control button, pull-out the tele-
scopic tube (7) as required. The tube length could very in the
range of 50–80 cm for CVC-7100 and 60–100 cm for other
models.
X Insert the flexible hose (3) in the telescopic tube (7).
X Put the required nozzle on the telescopic tube:
Multipurpose nozzle «Floor/Carpet» (20)
You can change the operating mode of the nozzle: with an
extended brush – for cleaning carpets, and without the brush –
for flat surfaces.
High-efficiency turbo-brush (23) is designed for conve-
nient and fast collecting of house moss and animal-hair.
Nozzles for narrow spaces and furniture (21,22): you
may use a crevice nozzle for cleaning hard-to-reach places, and
a special brush for cleaning upholstery.
The nozzles for narrow spaces and furniture (21,22) can be
stuck in the corresponding clips on the accessory bracket (24).
OPERATING INSTRUCTION
Using the appliance
1. Before using the appliance, select the re-
quired length of the power cord: yellow mark
at the power cord indicates the optimum
length of the power cord, whilst the red mark
indicates the maximum length.
Attention: Red mark is the limiter of the power cord
maximum length.
2. Connect the appliance to the power grid whose voltage shall
correspond to the voltage rating indicated on the appliance.
Use only grounded sockets.
3. Press «ON/OFF» (9) to switch on the vacuum cleaner. Press
