Remove the plug from the mains socket. Using
the Socket spanner (19) provided loosen the
3 bolts approximately 1/2 rotation counter-
clockwise(See F.1).Holding the blade clamp (7)
in position, using a piece of wood slides the
blade (8) out of the blade clamp (7) to remove
the blade from the blade clamp(See F.2)Note:
there is no need to remove the blade clamp
(7) as this can change the factory settings for
cutting blade height control. Before reinserting
a new or reverse blade, always clean both the
blade and the blade seat if dirty. Slide the blade
into the blade clamp in the correct orientation.
Check the blade is equal with the clamp. When
tightening the screws(10) ensure the correct
tightening sequence(
1
,
2
,
3
). Before starting,
rotate by hand to check the roller is free to
rotate.
Rotate the blade head by a further 180o and
repeat the procedure disassembling the second
plane blade
6. REPLACING A DRIVE BELT
Warning: 1. Remove the plug from
the socket before carrying out any
adjustment, servicing or maintenance.
2. The cutting blades will be turning and
may cause injury.
Loosen screw and remove belt cover (11),
remove worn drive belt from large pulley (13)
and pinion (12) and clean them (See G).lace the
new drive belt on the top of pinion and turning
it manually, press it on the large pulley (13)
(See H).Make sure the drive belt runs exactly
along the length grooves of the pinion and the
pulley.
Note: Place the belt cover (11) back on
top and tighten it with screw.
7. FITTING A DUST BAG
This accessory can be fitted by sliding the dust
bag inlet over the planer dust extraction (5) as
far as possible. The dust bag will reduce the
efficiency of the exhaust system and the bag
must be emptied frequently to maintain the
efficiency. To empty, open the zip on the rear of
the dust bag.
Note: This accessory can be used for
smaller jobs.
8. EXTERNAL DUST EXTRACTION
The dust extraction (5) is best connected to a
suitable external dust extraction machine e.g.
vacuum cleaner.
9. REPLACING CARBON BRUSH
Warning: Always be sure that the
tool is switched off and unplugged
before attempting to perform inspection
or maintenance.The motor brush can be
easily accessed on either the front or
back of the motor housing.
ATTENTION:
When servicing a tool, ALWAYS use only
identical replacement parts.
STEP 1: Locate the plastic motor brush caps on
both the front and back of the motor housing.
STEP 2: Remove the threaded brush cap on
accessible carbon brush (20) with a flathead
screwdriver and turn the screw in a counter-
clockwise rotation to loosen.
STEP 3: Gently remove the old motor brush.
STEP 4: Carefully insert the replacement
brush. Ensure the brush is completely inserted
into the holder and is seated properly and is
free to move inside its holder.
STEP 5: Replace the brush cap with the flat-
head screwdriver, turning clockwise to tighten.
Do not apply excessive force as this may
damage the access brush caps.
WORKING HINTS FOR
YOUR PLANER
Warning: Danger of kickback! Apply
the machine to the work piece only
when switched on.
1. STANDARD SURFACE PLANING
Set the desired cutting depth. Position the
front part of the base plate flat onto the work
surface. Switch the machine on and push your
planer forward and it will start cutting, always
maintain all of the base plate flat on the work
surface to prevent the cutting blade jumping.
Move the plane evenly over the work surface.
For most applications 0-2mm max cutting
depth will produce a good surface finish. It is
best to use small depths of cut and repeat the
planing process.
2. EDGE CHAMFERING
Using the V-groove in the base plate (15) you
can make a chamfer on the work piece edge
(See I). Guide the planer along the edge and
maintain a constant angle and force to produce
