ENGLISH
Menu item Selectable setting/item
Fader/Balance
Back
Fader/Balance Reset
Fader 0
Balance 0
Fader : Adjust the front and rear speaker output balance.
♦ F6 to R6; Initial 0
• When using a two-speaker system, set the fader to the center (0).
Balance : Adjust the left and right speaker output balance.
♦ L6 to R6; Initial 0
Press [ 5 / ∞ / 2 / 3 ] or drag [ ] to adjust.
Volume Adjust * 1 Adjust and store the auto-adjustment volume level for each source, comparing
to the FM volume level. The volume level will automatically increase or decrease
when you change the source.
• <Fix> appears if an FM broadcast is selected as the source.
♦ –12 to +12; Initial 00
Subwoofer Level Adjust the subwoofer output level.
♦ –06 to +08; Initial 00
High Pass Filter ♦ Through
♦ On
: Select when the subwoofer is not connected.
: Select when the subwoofer is connected.
Crossover Select the crossover frequency between the front/rear speakers and the
subwoofer.
♦ 80Hz, 120Hz, 150Hz
Amplifier Gain * 2 You can change the maximum volume level of this unit.
♦ Off
♦ Low
♦ High
: Deactivates the built-in amplifier.
: VOL 00 to 30 (Select this if the maximum power of the
speakers is less than 50 W.)
: VOL 00 to 50
Rear Speaker * 3 You can activate/deactivate the rear speakers.
♦ On
♦ Off
: Activate the rear speakers.
: Deactivate the rear speakers.
* 1 For “DISC/USB”: You can make the adjustments separately depending on the audio format—Dolby digital/MPEG
Audio and the others.
* 2 The volume level automatically changes to “VOL 30” if you change to <Low> with the volume level set higher than
“VOL 30.”
* 3 This setting takes effect only when Dual Zone is activated. ( 40)
Initial: Underlined
Sound
