Stage 3 – Инструкция по эксплуатации Evenflo ExerSaucer Animal Planet
Страница 14
11
10
Folding/Unfolding Stage 2
2. To unfold the ExerSaucer®, release the four tray
locks
F
by pulling them outward from the base
E
,
as shown.
Hold the base down with your foot, and pull the tray
upward. The tray will rotate as you pull and the legs will
lock in the upright position. The leg assemblies
B
will
lock onto the pedestals
G
.
Twist the tray to make sure all legs are locked properly.
IMPORTANT: Make sure all four leg assemblies
B
are
firmly locked onto the pedestals
G
before use.
12
G
B
G
F
E
C
E
B
1. To fold ExerSaucer®, ALWAYS remove baby and toy
bar
A
from ExerSaucer® before folding.
With ExerSaucer® flat on the floor, twist each leg
assembly
B
fully clockwise (the direction of the arrow)
until it stops in the position shown.
Fully depress one of the pedestal locking tabs
C
then
push on the leg assembly
B
; leg will partially fold. Repeat
this procedure for all four legs.
After pressing the fourth pedestal locking tab
C
, the
ExerSaucer® will fold with the tray
D
rotating toward the
base
E
. Make sure all four tray locks
F
are locked onto
the base before trying to carry ExerSaucer®.
Note: Make sure the legs are at the same height
adjustment or the ExerSaucer® will bind and not fold
properly (refer to page 8).
A
B
B
D
F
F
F
1. Remove toys and seat from the ExerSaucer®.
2. Follow Step 1 on page 10 to fold the ExerSaucer®, but
do not let the tray lock to the base.
3. Place your fingers beneath the legs
A
, as shown, and
push upward to disconnect the leg assemblies from the
pedestals
B
. Repeat for all four leg assemblies.
4. After all four legs have been disconnected from the
pedestals, remove tray assembly
C
from the base
D
.
Stage 3 is used for children who are walking age to 24 months.
IMPORTANT: Child should not use the activity table if they can not stand up by themselves.
Stage 3
Stage 3
C
C
D
E
F
A
B
C
C
G
6. Squeeze both locking tabs
G
on
each side of the tray to disconnect
and separate the tray halves
C
.
Re-position them as shown.
B
A
5. Turn tray
C
upside down and remove the large end cap
E
and the small end cap
F
from from beneath.
Ступень 3
Ступень 3
Ступень 3 предназначена для детей от начала хождения
до 24 месяцев.
Внимание: для использования игрового столика ребенок должен уметь
стоять без посторонней помощи.
1. Выньте игрушки и сиденье из игрового центра.
2. Выполните шаг 1 на стр. 12, чтобы сложить центр, но не позволяй-
те основанию и столику соединиться в фиксированном положении.
3. Подсуньте пальцы под опоры
А, как показано на рисунке, и на-
давите вверх, чтобы отсоединить опоры от подставок. Повторите
операцию для всех четырех опор.
4. После отсоединения всех четырех опор от подставок разъедините
столик
С и основание D.
5. Переверните столик
С и снимите большую заглушку Е и малень-
кую заглушку
F.
6. Сожмите два фиксирующих язычка
G на каждой стороне столика, чтобы
разблокировать и рассоединить поло-
винки столика
С.
Переставьте половинки, как показано
на нижнем рисунке.
