1.1 Description of the unit
The automatically operating Stiebel Eltron
HTT 4 and HTT 5 turbotronic hand dryers are
fitted with a proximity switch which activates
the fan when your hands are brought towards
it, (approximately 60 - 120 mm below the
warm air exit grille). The dryer automatically
switches off approximately 3 seconds after
the hands have moved away from the sensor.
The casing design does not allow cigarettes
or drinks etc to be placed on top, causing a
hazard. To retain this feature, when assem-
bling ensure that there are no gaps between
the wall and the unit.
In addition, the HTT 5 is protected against
damage by the cast aluminium casing.
1.2 Operation
In order to save energy and shorten the
drying time, vigorously shake wet hands over
the washbasin, then hold your hands beneath
the air exit grille rubbing them together in
the warm airstream.
1.3 Safety notes
During operation, temperatures of
over 90 °C can occur at the warm-
air exit grille. Due to the risk of
overheating this should not be covered.
In the event of overheating the temperature
safety cut out switches off the heating
element and the fan continues to run in a
cooling mode. The heating element switches
back on after approximately two minutes.
Ensure that the air inlet grilles on the
underside and rear of the dryer are always
kept open.
Trouble-free function and operational safety
can only be guaranteed if the original Stiebel
Eltron accessories and spare parts are used.
1.4 Care
When cleaning the casing, only use a soft
cloth, with a mild detergent if necessary, and
repolish with a soft cloth. Do not spray the
dryer with water or use any abrasive or
caustic cleaning agents.
1.5 Trouble-shooting
Like all proximity switches, the operation of
the sensor is impaired if it is covered. If this
happens the hand dryer automatically
switches off after 3 seconds preventing it
from running continuously. In the event of an
operating failure, check that the sensor has
not been covered. After the removal of any
objects the dryer should function as normal.
2.1 Configuration
1 Outer casing
2 Appliance
3 Warm–air exit grille
4 Fastening screws
5 Cable grommet
6 Mounting holes
7 Locking bolt
8 PVC-angle (only for HTT 5)
9 Fan
10 Heating element
11 Sensor
2.2 Technical data
2.4 Installation
The hand dryer should only be mounted on
a solid wall.
To install the unit follow these instructions:
2.4.1 Removal of front cover
HTT 4 (see page 3)
a. Remove the mounting screws (4).
b. Pull down the locking bolt (7).
c. Remove the front cover (1).
HTT 5 (see page 4)
a. Remove the mounting screw (4).
b. Pull down the locking bolt (7).
c. Slide off the outer casing (1).
2.4.2 Wall mounting
a. Transfer the four mounting points to the
wall using the drilling template and drill the
mounting holes. Note the length and
position of the power supply lead.
b. Screw the fixing screws into the wall.
c. Draw the power supply lead through the
cable grommet (5) at the rear panel of the
dryer.
d. Hang the unit to the wall, using the
keyholes on the rear of the unit.
e. Screw the appliance (2) to the wall.
2.4.3 Electrical Connection
The dryer is designed only for permanent
connection to 220 V – 240 V~ alternating current.
Please observe the rating place!
The PVC-angle (8) piece fixed in the
metalcase of the HTT 5 provides
insulation for the electric connection.
The voltage shown on the rating plate must
agree with the supply voltage. Cable should
be correctly sized in accordance with the
loading of the appliance.
The power supply cable must not be
located in the vicinity of the fan motor.
The maximum lenght of the cable
must not exceed 20 cm.
2.4.4 Mounting the front cover
HTT 4
a. Hook the button of the front cover onto
the front of the casing, and push top of
front cover towards the wall.
b. Push the locking bolt upwards to secure
the case.
c. Fix securing screws.
HTT 5
a. Push the outer casing over the body of the
unit until it touches the wall. Ensure that the
outer casing is square to the wall.
b. To lock the outer casing in position, lift the
casing slightly from the front, and push up
the locking bolt.
c. Fix securing screw.
2.5 Handing over
Hand over the operating and installation
instructions to the user. Explain the functions
of the unit and ensure that the user pays
particular attention to the safety instructions.
Loading information and technical data may
vary from country to country. Please note
the information from the rating plate for
specific details.
2.3 Regulations and
specifications
• All electrical installation work should be
carried out by a qualified electrician in
accordance with IEE regulations.
• The appliance must be separable from the
mains with an appropriate multipole device
with an air break of at least 3 mm.
Concerning this point a protective device,
line switch, fuses etc can be installed.
• This appliance must be installed (electrical
installation), commissioned and serviced by
approved service technicians in accordance
with these instructions.
• Any maintenance to the hand dryer should
be carried out by a qualified electrician. The
power supply should be disconnected before
removing the front cover. Only original
Stiebel Eltron parts should be used.
1. Operation instructions
for the user and the professional
2. Installation instructions
for the professional
English
3. Environment and
recycling
For guarantees please refer to the respective
terms and conditions of supply for your country.
The installation, electrical connection
and first operation of this appliance
should be carried out by a qualified installer.
The company does not accept liability for
failure of any goods supplied which are not
installed in accordance with the
manufacturer's instructions.
4. Guarantee
Recycling of obselete appliances
Appliances with this label must not be
disposed off with the general waste.
They must be collected separately and
disposed off according to local regulations.
I.
II.
III.
IV.
HTT 4 HTT 5
Weight 2,6 kg 4 kg
Nominal output 2600 W
Voltage 220 - 240 V, 50/60 Hz
