Shoulder Press Assembly Guide: Getting Started
3
Hardware Kit (not to scale)
The following pieces of hardware are provided on a shrink-wrapped card. Each part is labeled on the card for easy reference.
Table 1. Hardware kit contents
Fastener
Quantity
Socket head cap screw (M12 x 35 mm)
16
Flat washer (9 mm internal diameter)
9
Buttonhead cap screw (M8 x 15 mm)
1
Set screw (M8 x 6 mm)
8
Hex head cap screw (⁵₁₆-inch x 1¹₂-inch)
8
Flat washer (13 mm internal diameter)
16
Axle mount end
4
