14
Operation
OFF, week signal out-of-town stations may be
received.
• Goto Frequency: Selecting ON, you
can use GOTO button on the RC to select a
station’s frequency directly in radio mode.
• RT Scroll: You can select SLOW,
NORMAL or FAST RDS scroll speed.
• TA Volume: You can select LOW,
NORMAL or HIGH TA volume.
• Region: To set the AF searching region, the
default setting is ON. You can also set it to OFF.
• Adj Screen: After you touch this item, a
green cross appears in the top left corner of
the display and a tip: “Please press the button”.
Press the cross at place 1, then it will move to
another corner, press it again. Now it will move to
the third position, press it, then the last position.
After you pressed the green cross four times,
“Adjust successful” will appear. This procedure
is useful when some malfunction occur with the
touch screen, and it needs adjustment.
• Clock Adj: This option is to adjust the time.
Use touchable LEFT/RIGHT arrows to select
hours, minutes or seconds. Use touchable UP/
DOWN arrows to set the selected item.
Radio operation
User interface of Radio mode
1 2 3 4 5 6
7 8 9
When the unit is switched to Radio mode,
the above touchable user interface will be
displayed on the display.
1. Band indicator. Shows which band the
radio is tuned to.
2. AMS button. Briefly touch to scan the
current station. Touch and hold to tune
automatically.
3. BAND button. To select bands.
4. Preset number indicator. Shows what
preset is selected.
5. Frequency indicator. Shows which
frequency the tuner is tuned to.
6. The 6 stations of the current band. Briefly
touch to select the station. Touch and hold to
save the new frequency to this preset.
7. RDS button. Touch to access RDS menu.
8. SRC. Touch to go to Main menu.
9. SEEK+/- buttons. Briefly touch to change
the frequency step by step. Touch and hold to
tune automatically.
Band selection
Press BAND/TITLE button on the RC to
switch to the bands in the following order: FM1
- FM2 - FM3 – FM4 - AM1 - AM2.
Manual/automatic tuning
• Manual tuning: Press / buttons on
the RC repeatedly to change the frequency
upward or downward step by step.
• Automatic tuning: Press and hold /
buttons on the RC to start automatic seeking for
an available radio station downward or upward.
After being found the station will be played.
Local/distant selector
In radio mode, press LOC/SUB-T button
on the RC to select strong or weak station
reception. LOC appears on the display and only
local stations are available. When you turn it off
both distance and local stations can be received.
The function is invalid in AM bands.
Selecting stored station
In radio mode, press / buttons to select
the stored station upward/downward.
