tank (5) (5) (5) (5) (5) runs out of water, disconnect the appliance from the
mains outlet, wait till it cools down, refill the tank and plug the
appliance back into the power supply and continue the process.
Spray
Using the water spray (7) (7) (7) (7) (7) will help when ironing details of the
article (cuffs, trimmings, plackets, etc) or clothes, which demand
«•» (low temperature) ironing, when steam ironing is not possible.
Push the button several times to moisten the material.
5. When you have finished cleaning or ironing, do not forget to
switch the iron off by putting the steam control knob (9) (9) (9) (9) (9) and the
temperature control knob (10) (10) (10) (10) (10) into the «0» position and un-
plugging the appliance from the mains supply outlet.
CARE AND MAINTENANCE
Cleaning of the sole plate
! The scale on the sole plate can be removed
with a rough cotton cloth dampened with a
vinegar solution.
! Do not use any abrasive substances and ma-
terials to clean the sole plate.
Cleaning of internal parts of the appliance
SI-2550 iron is equipped with an anti-scale function which
protects it from an accumulation of scale: it does this with a built-in
permanent filter. Therefore the water hardness is reduced and the
useful service life of the iron is extended.
Warning: In areas with very hard water it is recommended
that you regularly remove scale from the appliance to
maintain it in good working order. Excess lime scale
may result in damage or malfunction of your product.
If in your area the water is soft and you have average amounts
of clothes to be ironed then we recommend you to de-scale every 6
months. If the water in your area is very hard or if you iron fre-
quently, then we recommend you de-scale once a month.
Your iron has a self-cleaning function, which allows you to clean
the internal parts of the appliance from scale or dust. To use this
function perform the following procedure:
1. Set the steam control knob (9) (9) (9) (9) (9) into the «0» position.
2. Fill the tank (5) (5) (5) (5) (5) with water to the «Max» level.
3. Place the iron in a vertical position and plug it into the mains
supply outlet.
4. Set the temperature control knob (10) (10) (10) (10) (10) into the «Max» position.
The light indicator (11) (11) (11) (11) (11) will light up showing that the iron is
being heated to the desired temperature.
5. When the iron reaches the maximum temperature, the light
indicator (11) (11) (11) (11) (11) will go out.
6. Whilst holding the appliance horizontally over a sink, set the
steam control knob (9) (9) (9) (9) (9) into the «Self-Clean» position. Hot
steam will discharge from the sole plate (12) (12) (12) (12) (12) removing the
