Sony KV-29FX30K - Инструкция (Страница 20)

20
Specifications
Additional Information
TV system:
Depending on your country selection:
B/G/H, D/K
Colour system:
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Channel Coverage:
VHF: E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K: R1-R12,
R21-R69
Picture Tube:
Flat Display FD Trinitron:
• KV-25FX30K: 25” (approx. 63 cm.
measured diagonally)
• KV-29FX30K: 29” (approx. 73 cm.
measured diagonally)
Rear Terminals
:1/
21-pin scart connector
(CENELEC standard)
including audio/video
input, RGB input, TV
audio/video output.
:2/q
21-pin Scart connector
(CENELEC standard)
including audio / video
input, S video input,
selectable audio / video
output and Smartlink
interface.
audio outputs (Left/
Right) - phono jacks
Front Terminals
q3 S Video input – 4 pin DIN
…3 video input – phono jack
3 audio input – phono jacks
headphones jack
Design and specifications are subject to change without notice.
Ecological Paper- Totally Chlorine Free
Sound Output:
2 x 14 W (music power)
2 x 7 W (RMS)
Power Consumption:
KV-25FX30K: 87 W
KV-29FX30K: 94 W
Standby Power Consumption:
0.5 W
Dimensions (w x h x d) :
KV-25FX30K: Approx. 655 x 509 x 476 mm.
KV-29FX30K: Approx. 746 x 569 x 516 mm.
Weight:
KV-25FX30K: Approx. 36 Kg.
KV-29FX30K: Approx. 46,5 Kg.
Accessories supplied:
1 Remote Control (RM-887)
2 Batteries (IEC designated)
Other features:
• Teletext, Fastext, TOPtext
• Sleep Timer
• Smartlink (direct link between your TV set
and a compatible VCR. For more
information on Smartlink, please refer to
the Instruction Manual of your VCR).
• TV system Autodetection.
01GBKV29FX30K.fm Page 20 Monday, April 2, 2001 9:47 AM
