19
GB
Connecting to external Audio Equipment:
Plug in your Hi-Fi equipment to the audio output sockets E if you wish to amplify the audio
output from TV. Next ,using the menu system, select the “Sound Adjustment” menu. Enter the
“Detail Adjustment” option and set “TV Speakers” to “Off”.
The audio level of the external speakers can be modified by pressing the volume buttons
on the remote control. Also treble and bass settings can be modified through the “Sound
Adjustment” menu.
Using Optional Equipment
1
Connect your equipment to the designated TV socket, as indicated in the previous page.
2
Switch on the connected equipment.
3
To watch the picture of the connected equipment, press the button repeatedly until the
correct input symbol appears on the screen.
Symbol Input Signals
1 • Audio / video input signal through the Scart connector D
• RGB input signal through the Scart connector D. This symbol appears only
if a RGB source has been connected.
2 • Audio / video input signal through the Scart connector F.
2 • S Video input signal through the Scart connector F.
3 • Video input signal through the phono socket C and Audio input signal
through B.
3 • S Video Input signal through the front S Video input jack A and Audio
signal through B.
4
Press button on the remote control to return to the normal TV picture.
For Mono Equipment
Connect the phono plug to the MONO (L/G/S/I) socket on the front of the TV and select
3
or 3 input signal using the instructions above. Finally, refer to the “Sound Adjustment”
section of this manual and select “Dual Sound” “A” on the sound menu screen.
S
S
S
Additional Information
