30
Handling and operation (Fig. B)
Preparation for operation
Before first usage (or after long storage) wash the jug (9), lid
(8) and feeder opening stopper (7) in hot water with washing-
up liquid, rinse and dry well. Keep your hands away from
cutting blades (14) – they are sharp.
Operation manual
1 Place the motor housing (10) on dry, firm, and horizontal
surface, near mains supply outlet and out of the reach of
children.
Arrange the supplying cord so that it does not hang from
the table or board and it can not be pulled or dragged by
accident.
2 Connect the plug into the mains supply outlet.
3 Place the jug (9) so, that the protrusions at the bottom
part of the jug (9) were fitted with the protrusions in top part
of motor housing (10).
4 After proper assembling of the jug, the blue highlight
shall glow around the control panel (11).
The handle of the blender jug (9) shall be placed on the
right side of the appliance.
5
Put the ingredients into the jug (9).
6 Do not fill in over 1500 ml marked on the blender
jug (9). In such case, the content of the jug can lift the lid
(8) when the motor starts up.
7 Before you use the stand blender, assemble the lid (8)
on the blender jug (9) so, that its protrusion was in line with
the protrusion in the jug.
ATTENTION: Before you insert the lid (8) moisture the
lid gasket with water.
8
Insert the lid overlay (7) into the inlet in the lid (8) so that
the protrusions of the overlay enter the cuts in the lid inlet
and turn it left or right until it moves.
Do not start the stand blender without the feeder
opening stopper (1), especially, when you use solid
ingredients. They can be thrown out of the opening.
9
Switch mixing on pressing speed I (2), speed II (5) or
CLEAN/PULSE (6).
10 Press ON/OFF switch to turn off the appliance.
Operating with speed I or speed II, the appliance is
switched off automatically after 2 minutes.
11 CLEAN/PULSE function
Pressing CLEAN/PULSE
●
(6) button shall cause short
operation with maximum speed.
Do not operate longer than 3 minutes, otherwise it can
●
get overheated.
If you need to add some new ingredients during blender
●
operation, turn and lift feeder opening stopper (7), feed
the ingredients into the opening, then replace the stopper
again (7) and turn it left or right until it runs.
Make sure, that the ingredients you add, shall not
●
increase the capacity inside the jug exceeding 1500 ml
marking on the jug (9).
12 ICE function
Check if the stand blender is clean, before you use it for
●
crushing ice. Otherwise wash it thoroughly with clean
water. Any residues of washing agent can influence the
taste of crushed ice and shall cause that the drink we
add the ice to, shall loose its taste.
In case you want to crush ice, use 6 to 10 ice cubes
●
(max. 2 cm) in given time, and then add 15 ml (1 spoon)
fresh cold water.
Assemble the lid
●
(8) including overlay (7) on the appli-
ance and press ICE switch.
ICE feature operates for 30 seconds, then the appli-
ance switches off automatically.
Do not try to crush the ice without adding some water
into the jug.
Press the lid (8) with one hand during ICE feature is on.
After operation
To switch off the stand blender press and hold ON/OFF
switch for 3 seconds, until the blue highlight around the
control panel (11) is off.
Hold the motor unit
●
(10) with one hand, catch the jug
handle with the other hand and remove it from the motor
unit (10) turning it counter-clockwise.
Remove the lid
●
(8) from the jug (9).
Unplug the appliance from the mains supply outlet when
●
it is not in use.
Cleaning and maintenance (Fig. C)
Clean after operation as soon as possible, to prevent
the pulp accumulation inside the jug (9).
1
Pour approximately 1 liter of water to the blender jug (9)
and start-up the appliance for approximately 30 seconds and
hold the CLEAN/PULSE button.
2 Then empty the blender jug (9), turn it upside-down and
dry.
3 If necessary, clean the jug (9), lid (8), feeder opening
stopper (7) and blades (14) in warm water with wash-up
liquid.
Then rinse it under clean running water and dry.
●
If you left the jug for longer time without cleaning and
●
some particles glued to the jug inner, use nylon brush.
We do not recommend cleaning the jug
●
(9), blades (14),
lid (8) and feeder opening stopper (7) in dish washer.
Aggressive cleaning agents applied in such device can
influence negative the surface conditions.
