It may be necessary to press the burst of steam button a few times
to start this function.
For optimum steam quality, do not operate the Burst Of Steam more
than three times after the pilot light goes off.
Hold the iron some centimetres away from delicate garments (arti-
ficial, silk, velvet etc.), otherwise they can be damaged.
Build-in anti-scale system
(concerning irons type 28Z020, 28Z021, 28Z022)
The build-in anti-scale cartridge is designed to reduce the build-up of lime
scale that occurs during steam ironing. This will prolong the working life of
your iron, although it does not stop the natural process of build-up of lime
scale completely.
Self-cleaning
This function removes the scales and minerals built up in the Steam
Chamber.
The iron will remain in the best condition if this function is performed at
least once a month or more regularly depending on the hardness of the
water used.
Fill the iron as described in “How to fill water”.
–
Connect the iron to a suitable mains supply outlet. See „Preparation
–
for operation”.
Turn the
–
Temperature Dial (2) in clockwise direction to „MAX“ position.
Control light (11)
–
glows, indicating that the iron is on.
Control light goes off when the required temperature is reached.
–
The iron is now ready for use.
Wait for one more cycle; pilot light glows and goes off.
–
After finishing move the
–
Temperature Dial (2) in anti-clockwise
direction to „
MIN”; the iron is switched off.
Disconnect the iron from mains supply outlet.
–
Hold the iron horizontally over a sink.
–
Press and hold the
–
Self-Cleaning Knob (8).
Steam and boiling hot water will drain from the holes on the soleplate
–
washing away the scales and minerals that have built up inside the
Steam Chamber.
Gently move the iron back and forth until the water tank is empty.
–
When Self-Cleaning is complete, release the Self-Cleaning Knob.
–
Rest your iron at the stand and allow to fully cool down.
–
Wipe the soleplate with a cold damp cloth.
–
Caution!
Keep skin/body away from the hot water.
Anti-Drip System
The system, which is designed to prevent
–
automatically water escaping from the
sole-plate when the iron is too cold.
During use, the anti-drip system may
–
emit a loud clicking sound, particularly
during heat-up or whilst cooling down.
This is per-fectly normal and indicates
that the system is functioning correctly.
Auto shut-off feature
(Concerning iron 28Z021, 28Z022)
The Auto shut-off feature will operate automatically when the iron is un-
attended and it is connected to a mains supply outlet.
AUTO SHUT-OFF IN HORIZONTAL POSITION
1. The iron will switch off automatically after approximately 30 seconds,
if it is immobile in the ironing position (horizontal).
2. You can hear a sound signal.
The auto switch-off pilot light (4), shall
flash indicating that the iron changed to auto switch –off mode.
3. Simply moving the iron, it will back on and the auto switch-off function
shall be wyzerowana. You will hear a sound signal, the pilot light shall
go off, whereas the
pilot light indicating heater in operation shall
glow (11) – the iron shall reheat again.
AUTO SHUT-OFF IN VERTICAL POSITION
1. The iron will switch off automatically after approximately 5-10 min-utes,
if it is immobile in the rest position (vertical).
2. You can hear a sound signal.
The auto switch-off pilot light (4), shall
flash indicating that the iron changed to auto switch –off mode.
