81 GW28-029_v02
How to fill the water
Disconnect the iron from mains supply outlet. –
Move the – Steam Control Knob (7)
to position.
Release the – water inlet cover (5)
and fill water through the water inlet
hole.
Fill up to the „ – MAX” level marked on
the side of water tank.
Close the – water inlet cover (5).
Note:
For best result, it is advisable to use demineralised water or distilled
water. Do not use chemically descaled water or any other liquids.
Preparation for operation – first ironing
Remove any protective films or sticker from the – soleplate (1) and the
cabinet, if any.
Unwind and straighten the – power cord (13).
Fill the iron as described in “How to fill water”. –
Connect the iron to a suitable mains supply outlet. –
Turn the – Temperature Dial (2) in clockwise direction to ●●● position
– control light (11) glows.
Control light goes off when the required temperature is reached. –
Move the – Steam Control Knob (7) to position.
Steam starts coming out from the holes in the sole plate after putting –
the iron in horizontal position and after pressing the Burst of Steam
Button (9).
Begin first time ironing with an old towel. –
The steam is not generated after the water tank is emptied. –
The preparation work is completed. The iron is now ready for proper use. –
After operation
Move the – Temperature Dial (2) in anti-clockwise direction to „MIN”;
the iron is switched off.
Move the – Steam Control Knob (7) to position.
Disconnect the iron from mains supply outlet. –
When the iron gets cool completely, store it vertically in a safe place. –
Spraying
This function can be used any time –
and is not affect any setting.
Fill the water tank as described in –
How to Fill Water.
Aim the – nozzle (6) to the garment.
Press the – Spray Button (10).
It may be necessary to press the spray button a few times to start this –
function.
Dry ironing – Always follow the garment manufacturer’s ironing
instructions mentioned at the garment label.
Unwind and straighten the – power cord (13).
Move the – Steam Control Knob (7) to position.
Connect the iron to a suitable mains supply outlet. –
Turn the – Temperature Dial (2) in clockwise direction to; set ●, ●● or
●●● position.
Control light (11) – glows, indicating that the iron is on.
Control light goes off when the required temperature is reached. The –
iron is now ready for use.
Move the – Temperature Dial (2) in anti-clockwise direction to „MIN”;
the iron is switched off.
Disconnect the iron from mains supply outlet. –
When the iron gets cool completely, store it vertically in a safe place. –
Steam ironing – Always follow the garment manufacturer’s
ironing instructions mentioned at the garment label.
Unwind and straighten the – power cord (13).
Fill the iron as described in “How to fill water”. –
Connect the iron to a suitable mains supply –
outlet.
Turn the – Temperature Dial (2) in clockwise
direction to ●●● position. (For optimum steam
quality, do not use ● or ●● setting for steam
ironing).
Control light (11) – glows, indicating that the iron is on.
