Vacuuming upholstery, mattress, etc.:
Open the compartment lid and take out the small nozzle.
Small nozzle is used for upholstery, mattress and curtains cleaning. It is equipped with a tape for picking up threads,
which enables exact picking up the threads, fine fibres, etc. We recommend reducing suction power during such activity.
Vacuuming gentle fabrics and rough objects:
Open the compartment lid and take out the small brush.
Small brush is used for vacuuming: libraries, picture frames and windows.
We recommend reducing suction power during such activity.
AFTER OPERATION
Switch off pressing ON/OFF button.
Unplug from mains supply outlet.
Rewind the cord pressing cord rewind button. Hold the plug when rewinding, do not allow the cord to get entangled and the
plug to bump the casing.
You can store the vacuum cleaner in both horizontal and vertical positions. The hose can remain fitted, but please be careful not
to bend it too much.
Horizontal storage:
insert the gap nozzle or small nozzle with small brush on it on the accessories handle of tel-
escope pipe,
insert the handle located in back part of brush – nozzle into the handle socket at the backside of
the vacuum cleaner near the supply cord inlet.
Vertical storage:
insert the accessories - like for horizontal storage,
insert brush – nozzle on telescope pipe,
insert the handle into the handle socket at the bottom of the vacuum cleaner next to front wheel.
FULL DUST COMPARTMENT INDICATOR
Full bag indicator glowing (red colour), when the nozzle or brush is above the cleaned surface, informs us that it is necessary to
empty dust compartment.
Full bag indicator can activate also in case of blocked sucking hose or one of connected accessories. In such case, remove the
hose from front lid and clean the hose and connected accessories.
DUST BAG – DUST COMPARTMENT
The vacuum cleaner is equipped with disposable dust bag. You can purchase new dust bags in ZELMER outlets.
DUST COMPARTMENT (BAG) EXCHANGE
Remove and dispose the dust bag when full. Dust bag replacing is necessary when you notice that
full dust bag indicator is covered with red colour, safety valve opens, the suction is significantly lower,
and dust bag is full.
When collecting wool particles, the dust bag can be full although the indicator shall not work.
In such case exchange the bag with a new one:
switch off the vacuum cleaner and unplug it from the mains supply outlet,
remove the hose from the lid (press the side button at the hose ending),
press upper lid locking button located in front part of the lid and open it upwards,
lean the dust bag locker out of the vacuum cleaner - in direction indicated by the arrows on the locking button,
remove full dust bag and dispose it,
insert a new dust bag – in direction indicated by the arrows on the bag,
close the lid.
ATTENTION!!! – Insert the dust bag carefully, so that the inlet of the dust bag got into rubber flange inside the
vacuum cleaner chamber.
Do not vacuum with damaged dust bag. Replace it with a new one.
Do not vacuum without dust bag. The vacuum cleaner is equipped with a blockade, which pre-
vents closing the lid without inserting dust bag.
OUTLET AND INLET FILTER
Inlet and outlet filters should be replaced with new ones or rinsed twice a year or when they are visibly dirty.
ATTENTION!!! – Replace both in case of damage.
INLET FILTER EXCHANGE
The inlet filter is located inside the dust bag chamber – behind the fasteners fastening it at the air inlet grid. Exchange it the fol-
lowing way:
switch off the vacuum cleaner and unplug it from the mains supply outlet,
open the front lid and remove the dust bag as described in chapter „Dust compartment (bag) exchange”,
take the inlet filter out of the fasteners and runners upwards,
insert clean inlet filter carefully behind the fasteners and into the runners up to the very bottom of the chamber (it can be a new
one or the same – rinsed in water),
ATTENTION!!! – Dry the rinsed filter before assembling.
insert the dust bag and close the front lid.
WYMIANA FILTRA WYLOTOWEGO (MIKROFILTRA)
Outlet filter (micro-filter) is located at the backside of vacuum cleaner – under the filter protecting grid.
Exchange it the following way:
switch off the vacuum cleaner and unplug it from the mains supply outlet,
press the filter protection lever out of the vacuum cleaner,
take out the filter protection upwards,
remove the dirty outlet filter (micro-filter) out of 4 hooks and replace it with a new one
insert it thoroughly on four hooks (it can be a new one or the same – rinsed in water),
ATTENTION!!! – Dry the rinsed filter before assembling.
replace the filter protection pressing it gently.
ATTENTION!!! – Properly assembled protection shall lock inside the vacuum cleaner casing.
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Horizontal
storage
Handle
socket
Handle
socket
Vertical
storage
