TV top control, front and rear panels
TV top control panel
Button/Terminal
Function
Page
1
!
Turn off or turn on the TV.
4
2
Remote control sensor.
-
3
Wake Up indicator.
11
3
1
Standby indicator.
4
4
i
Headphone jack.
-
5
t2
Video input terminal 2.
8
6
PROG +/–
Select program number.
-
7
2
+/–
Adjust volume.
-
8
t
Select TV or video input.
8
WEGA GATE menu operations
6
,
7
V,v,B,b
Select and adjust items.
12
8
Confirm selected items.
12
9
WEGA GATE
Display or cancel WEGA GATE menu.
12
0
SOUND MODE
Select sound mode options with a 5-Band Graphic
10
(KV-BZ21M81 only)
Equalizer display.
qa
8
Antenna input terminal.
8
qs
T
Monitor output terminal.
8
qd
Component video input terminal.
9
qf
t1
Video input terminal 1.
8
TV front
panel
KV-BZ21M71/BZ14M71
KV-BZ21M81
KV-BZ21M71/BZ14M71
★
The earphone jack will be labeled as for KV-BZ14 only.
