Instruction manual Eng
You can operate the appliance both on Control Panel and with Remote
Control Unit.
1. Press ON/OFF (A), the red power light will be turned on. The appliance
begins to work on ANION mode at middle speed air flow.
2. Set wind speed (H,M,L) by pressing WIND button (B).
3. Press ANION (B), the machine will generate negative ions at low
speed air flow.
4. Press the TIMER (D) button to set timer (1hr, 2hr, 4hr, 8hr). When
the indicator is not on, that means the timer is not set.
Caution. Turn off the air purifier and disconnect it from the power-
point before anydisassembly and assembly work.
Front cover
Pull off the bottom part of the front cover and hold it upward to take
it off.
Pay attention to the interlock switch at the top right corner which will
disconnect the power source when the front cover is open. In case of
the interlock switch was destroyed, the purifier would not work.
Hang the two hooks onto the frame and press the front cover to
assemble it .
OPERATION GUIDE >
DISASSEMBLY
AND ASSEMBLY
>
Front cover
