JVC KW-XG707 - Инструкция (Страница 27)

ENGLISH
27 SETTINGS
3
Select or adjust the selected PSM item.
4
Repeat steps 2 and 3 to adjust other PSM
items if necessary.
5
Finish the procedure.
You can change PSM (Preferred Setting Mode) items
listed in the table below and on pages 28 and 29.
1
Enter the PSM settings.
2
Select a PSM item.
Continued on the next page
* 1 When you adjust the bass, mid-range, treble, or loudness, the adjustment you have made is stored for the currently
selected sound mode (iEQ) including “USER.”
* 2 If you are using a two-speaker system, set the fader level to “00.”
* 3 The adjustment will not affect the subwoofer output.
* 4 Depending on the amplifier gain control setting. (See page 29 for details.)
General settings — PSM
Indication Item
( : Initial) Setting, [reference page]
DEMO
Display demonstration • DEMO ON
• DEMO OFF
: Display demonstration will be activated automatically if no
operation is done for about 20 seconds, [4].
: Cancels.
SCREEN
Spectrum analyzer
screen METER 1,
METER 2,
METER 3,
METER 4,
METER 5,
SAVER 1,
SAVER 2, OFF : You can select the different visual effect display during playback.
METER 1 – METER 5: The spectrum analyzer meter changes
according to the audio input level.
SAVER 1 – SAVER 2: The spectrum analyzer meter changes the
pattern repeatedly.
OFF: Cancels.
CLK DISP * 1
Clock display
• ON
• OFF
: Clock time is shown on the display at all times when the power is
turned off.
: Cancels; pressing DISP will show the clock time for about 5 seconds
when the power is turned off, [4].
* 1 If the power supply is not interrupted by turning off the ignition key of your car, it is recommended to select “OFF” to
save the car’s battery.
