Using the Nozzles
Use of the Electrical Vacuum Brush
ROTOSOFT
(depending on model)
The electrical vacuum brush is suitable for car-
pets and smooth floors.
Engage electrical vacuum brush with connector.
The brush is switched on by placing the vacuum
cleaner in operation and operating the On but-
ton (Figure 1/N) on the handle. Pick up larger
items such as material remnants, paper, etc.
from the floor to avoid jamming the rollers.
Press on the nozzles:
Connect the floor nozzle to the suction tube.
The connection must engage noticeably.
Press the release button to remove the floor
nozzle from the suction tube.
Using the VARIO Floor Nozzle
(depending on model)
For the daily care of carpets and hard floors. The
floor nozzle can be switched over manually:
with the brushes protruding for smooth floors,
and with the brushes withdrawn for carpets.
A furniture brush, crevice nozzle and upholstery
nozzle are stored in the accessories compart-
ment.
To met your specific requirements for room
care, three different items are included with
the vacuum cleaner in an integrated accesso-
ries compartment. Open the compartment by
gently pressing the button as shown in the
Figure.
The nozzles can, depending on your needs, be
fitted to either the suction tube or the suction
hose handle.
Crevice Nozzle
For vacuuming crevices, gaps and corners.
