Инструкция по эксплуатации Sony ICF-306

Fm/am radio

background image

ICF-306_RU2 [GB/RU/KZ]








For Better Reception/Для улучшения приема/
Сигналды жақсы қабылдау үшін



Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
Do not expose the appliance to naked flame
sources (for example, lighted candles).
Batteries or batteries installed apparatus shall
not be exposed to excessive heat such as
sunshine, fire or the like.
The nameplate and important information
concerning safety are located on the bottom

FM/AM Radio
Manufacturer: Sony Corporation, 1-7-1, Konan,
Minato-ku, Tokyo 108-0075, Japan
Made in China
Importer on the territory of the CU:
CJSC “Sony Electronics”, 123103, Moscow,
Karamyshevsky lane 6, Russia.
Organization accepting on the territory of
Kazakhstan the claims from the users:
CJSC “Sony Electronics”
Representative office in Kazakhstan
Dostyk avenue, bld. 117/7, 050010, Almaty,

Production Date

The date of manufacture is specified on the
barcode label on the carton and the product in
the following format: MM-YYYY, where
MM-month and YYYY-the year of

This product is designed for listening to FM
and AM radio stations.


• Operate the unit only on 3 V DC with two R6/

LR6 (size AA) batteries.

• Avoid exposure to temperature extremes,

direct sunlight, moisture, sand, dust or
mechanical shock. Never leave in a car parked
under the sun.

• Should anything fall into the unit, remove the

batteries, and have the unit checked by
qualified personnel before operating it any

• Since a strong magnet is used for the

speaker, keep personal credit cards using
magnetic coding or spring-wound watches
away from the unit to prevent possible
damage from the magnet.

• When the casing becomes soiled, clean it

with a soft dry cloth moistened with mild
detergent solution.

• Never use abrasive cleansers or chemical

solvents, as they may deform the casing.

• Make sure not to splash water on the unit.

This unit is not waterproof.

• Listening with this unit at high volume may

affect your hearing. For traffic safety, do not
use this unit while driving or cycling.

• Under certain circumstances, especially when

the air is very dry, it is not uncommon to
experience a discharge of static electricity, or
shock, when your body comes in contact with
another object, in this case the ear buds
touching your ear(s). The energy from this
natural discharge is extremely small and is
not emitted by your product but rather a
natural environmental occurrence.

• Depending on the strength of radio signals,

the TUNE (tuning) indicator may not light up
even if a broadcast is being received.
Furthermore, the indicator may light up
incorrectly due to extraneous noise even
when a broadcast is not being received. Use
the TUNE indicator as a reference.

• When connecting headphones (not supplied)

to the unit, use headphones with a stereo
(3-pole) or monaural (2-pole) mini plug.
Sound may not be heard when using other
types of plugs.

* When connecting stereo

headphones, you will hear monaural
sound in both ears.

1 ring

2 rings

Other types
of plugs
cannot be

plug types

3 or more rings

mini plug

mini plug*

When to replace the batteries

Replace all batteries with new ones when the
BATT (battery) indicator becomes dim or the
sound becomes weak.
Notes on batteries

• Do not mix an old battery with a new one or

mix different type of batteries.

• When you are not going to use the unit for a

long time, remove the batteries to avoid
damage from battery leakage and corrosion.

• Check if the batteries are inserted in the

correct orientation (

 and ) when the radio

does not turn on after battery replacement.

• Batteries have a recommended use-by date

for proper use. When using expired batteries,
battery life will be extremely short. Check the
use-by date on the batteries and if they are
expired, replace them with new ones.

If the battery compartment cover comes

Insert the right hook tab
of the lid into the right
hole, then put the left
hook tab on the edge of
the opening and slide it
slowly until it fits into the
left hole.

If you have any questions or problems
concerning your unit, please consult your
nearest Sony dealer.


Frequency range: FM: 87.5 MHz – 108 MHz/

AM: 530 kHz – 1,605 kHz
Speaker: Approx. 6.6 cm dia., 8 Ω


 (headphones) jack (ø3.5 mm mini

Power output: 100 mW (at 10 % harmonic
Power requirements: 3 V DC, two R6/LR6

(size AA) batteries
Battery life*: Approx. 100 hours (FM reception)/

Approx. 110 hours (AM reception)

* When listening through the speaker on alkaline

batteries manufactured by Sony (LR6SG). The actual
battery life varies significantly depending on battery
type (such as rechargeable batteries), usage and

Dimensions (W/H/D): Approx. 190.1 mm ×
97.3 mm × 51.3 mm (incl. projecting parts)
Mass: Approx. 400 g (incl. batteries)

Quantity: Unit (1)

Design and specifications are subject to
change without notice.

R6/LR6 (AA)



Operating Instructions
Инструкция по эксплуатации

Басқару нұсқаулары

FM/AM Radio


©2015 Sony Corporation Printed in China
