6
l Clean carpets and wall-to-wall carpets
without using the brush. Press the tip
switch marked with the carpet symbol
and the brush is raised.
l Smooth floors such as PVC, parquet or
tiles are best cleaned and cared for
suing the brush. To do so press the tip
switch with the symbol for smooth floors
and the brush will come out.
Sofa brush
You can use this to clean the dust from
books or sensitive objects such as picture
frames etc.
This nozzle is suitable for the careful
cleaning of upholstered furniture,
mattresses, cushions, curtains etc.
Crevice nozzle
This nozzle is suitable for sucking clean
the folds in cloth, joint cracks and corners
or niches that cannot be reached with the
floor nozzle.
PREVENTION
Switch off the vacuum cleaner
immediately if the air intakes, the floor
brushes or the telescopes tube becomes
blocked. Before starting the vacuum
cleaner up again remove the substance
causing the blockage:
1. Never use the vacuum cleaner in the
immediate vicinity of hot bodies and do
not suck up hot objects such as
cigarette ends or ashes.
2. Only place the plug in the socket when
your hands are dry.
3. Please remove large of sharp objects
from the floor before using the vacuum
cleaner to avoid any possible damage to
it.
4. Do not pull by the mains cable when
pulling out the plug.
Danger!
The vacuum cleaner is provided
with a plug and an electric cable. If the
plug or the cable are damaged a qualified
electrician must be called to repair them.
ASSEMBLING THE VACUUM CLEANER
Caution!
Before assembling or disassembling the
accessories always ensure that it has been
unplugged from the mains socket!
Connecting your vacuum cleaner
1.Assembly and disassembly of the
tube
l Montage:
Insert the tube in the air intake opening.
Push the tube in until it locks in place.
l Disassembly:
Take the tube from the air intake after
disconnecting from the mains socket.
2. Assembling the telescopic tube and
accessories
2.1: Remove the telescopic tube from
the hand grip.
l Set the telescopic tube to the cor-
rect length.
l Push the telescopic tube slide forwards
and pull out the lower part of the tube
to the extension length required. Then
simply let go of the slide and let it snap
into place.
7
2.3: Fix the floor brush to the telescopic
tube.
2.4: Suitable for everyday cleaning of the
carpet and of wooden floors.
OPERATION
Vacuum cleaning
Before using the device first roll out a
sufficient length of electric flex cable and
plug into the mains socket. The yellow
mark on the electric flex cable is the
maximum length that must not be
exceeded.
To switch on the device press the foot
pedal button on the casing with your
foot. Pull the device behind you like a
sledge when working with it.
Regulating the suction power
You can set the suction power on the
device individually as you require it using
the suction regulator. We recommend
using minimum suction power for delicate
materials.
Select medium suction power for
mattresses, upholstered furniture and
carpets. Select maximum suction power
for tiled, wood and other robust floors.
Secondary air valve
The secondary air valve is at the handle
l Opening: pull upwards
l Closing: push downwards
You can adjust the suction
power by using the
secondary air valve.
The wider the secondary air
valve is opened, the less
the suction power and vice-
versa.
Open the secondary air valve to prevent
curtains and the like from being sucked in.
Choose:
Minimal suction power for curtains and
sensitive materials.
Medium suction power for upholstery
cushions, mattresses, carpet floors.
Maximum suction power for tiled, wooden
and robust floor surfaces with heavy
soiling.
After vacuum cleaning
Switch off the device when you have
finished cleaning:
To do this press the foot button on
the device with your foot of by hand.
After this pull the mains plug from the
socket.
To roll in the cable press foot pedal
and hold it in position. The cable will be
rolled back automatically onto the
installed cable drum and disappear
completely into the device up to the plug.
The floor nozzle can be kept attached to
the vacuum cleaner for ease of storage
after use.
HEPA FILTER CLEANING SYSTEM
The cyclone vacuum cleaner function
without needing a dust bag. The sucked
up dirt is forced into the dust container by
force of the air jet instead. The air is
cleaned by a washable permanent filter
(HEPA filter) in the dust container, motor
protection filter and an exhaust air filter.
Caution!
Never vacuum clean without a
filter or with a damaged filter. The dust
