Saturn ST-VC7298 - Инструкция (Страница 4)

6
break.
Caution: Do not transfer the appliance
when the fixing hook is used.
Cleaning tools
Crevice tool:
For cleaning corner edge and draws etc,
Where is difficult to reach, such as gaps
and the keyboard, bookshelf and win-
dows.
Convertible brush:
Turn the crevice tool 90°and attach it on
the extension tube for cleaning bed,
sofa, curtain etc.
Use of the selector on floor brush:
Bristles extended for carpets.
Bristles retracted for hard floors.
If the angled pipe has blockage, insert it
into the air-intake and switch the appli-
ance on.
Cleaning and maintenance
Empty the dust container
After removing the flexible hose, press
the cover lock button and open the dust
container.
Remove the dust filter from the con-
tainer.
Replace the dust filter in the container.
Close the dust container until it is locked
in the position.
Change filter
Replace the motor filter:
Open the dust container and remove the
motor filter. Fix the new filter in the
position
Replace the outlet filter:
Detach the grille by pulling firmly away
from the appliance, remove the outlet
filter and replace the new filter. Fix the
grille again
Clean the filter
7
Clean the filter in water and allow them
to dry completely before replace them.
Clean the cloth dust bag
Clean the cloth dust bag with water and
a little detergent (if needed). Allow the
bag to dry completely before replacing.
Error detection:
Before you contact our services center,
please check the following points:
Problem
Possible
reason Active
Motor does
not start -Power card
not
firmly
plugged
into outlet
-Outlet
damaged
-Cleaner
not switch
on
-Plug unit
firmly
-Check the
outlet
-Switch on
the appli-
ance.
Suction
power
is
weaker
-Unit
clogged
-Dust filter
needs
cleaning
-Dust con-
tainer not in
position
-Filter
blocked -Remove
the block-
age
-Clean the
dust filter
-Close the
dust con-
tainer
-Clean the
filter
The wire
cannot be
winded
completely.
The wire
may diverge
the
wire
wheel.
Draw the
wire
a
little then
rewind.
The wire
cannot be
draw out.
The wire
may wind
disorder
Press the
rewinder
button and
try again.
Speed ad-
just
does
not work
Appliance is
defective Repair the
appliance
(only spe-
cialist)
Power card
winds un-
wanted
back Rewind
mechanisms
is defective Repair the
appliance
(Only spe-
cialist)
The dust
container
can not be
closed
Dust filter is
not in the
position Fix the
dust filter
and
try
again
Specifications
Rated voltage: 220-230V AC
Rated frequency: 50Hz
Power: 1600 W
Rated current: 7,2A
Set
Vacuum cleaner body 1
Crevice nozzle 1
Floor brush 1
Instruction manual with
Warranty Card 1
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local
regulations: hand in the non-working
electrical equipments to an appropriate
waste disposal centre.
The manufacturer re-
serves the right to
change the specifica-
tion and design of
goods.
