8
frequency energy to treat the material and is intended to be used in a
local home or a facility connected directly to the distribution of
electricity at low voltage supplying domestic premises (Class B).
Household use only
Product description
grill rack
door interlock
oven door
oven foot
rotating ring glass turntable
oven cavity rotating axis
housing
Door lock
Microwave oven door must be properly closed in order to operate.
Viewing window
Allow user to see the cooking status.
Rotating axis
The glass turntable sits on the axis, the motor underneath it drives the
turntable to rotate.
Rotating ring
The glass turntable sits on its wheels, it supports the turntable and
helps it to balance when rotating.
Turntable
The food sits on the turntable, its rotation during operation helps to
cook food evenly.
9
- Place the rotating ring first, and then fit the turntable onto the
rotating axis and make sure that it is geared in properly.
Control panel
See below in details (the control panel is subject to change without
prior notice).
Waveguide cover
It is situated inside the microwave oven, next to the wall of control
panel. Please see figure below.
Never remove the waveguide cover.
Grill rack is used to place the roasting food on it.
OPERATION OF CONTROL PANEL
