Инструкция по эксплуатации Saturn ST-FP8051
Страница 3
![background image](/files/770099/content/doc003.png)
3
bidden to start the unit or press the
control button by wet hands.
10. The water temperature should not
be over 60
℃ when cleaning the unit.
11. Do not run this unit long-time, oth-
erwise the inner parts will be dam-
aged.
12. When the motor is running, do
not insert your finger or other
objects into the machine and
container.
13. The instructions for food processors
and blenders shall warn of potential
injury from misuse. They shall state
that care shall be taken when
handing the sharp cutting blades,
emptying the bowl and during
cleaning.
14. Switch off the appliance and dis-
connect from supply before changing
accessories or approaching parts
that move in use.
15. If the supply cord is damaged, it
must be replaced by the manufac-
turer, its service agent or similarly
qualified persons in order to avoid a
hazard. Do not use the appliance if
the rotating sieve is damaged.
Safety protection: the motor is
equipped with protective setting, which
will turn off the unit automatically while
overloading and re-operate it after
cooling.
Name of parts
Instruction for use of juicer
Cut the fruit or vegetable into
pieces and make sure that they
can go through the guide hole.
Put the separating trough on the
base and turn it tight clockwise.
Put the filter into position on the
connector and then put on the
transparent cover and lock the
cover, the inner lock switch will
be connected automatically.
Put on the fruit press on the
transparent cover and then lo-
cate the juice cup (with foam
filtering plate inside) under the
juice outlet (make sure the cup
in correct direction, the side
with concave surface should be
towards the main unit).
4
Connect the power and turn the
control button to “I”, then the
unit starts to work.
Put the cut fruit or vegetable in
the plate and push them into the
guide hole with the fruit /
vegetable. Press and make sure
the volume is not more than1/3
of the guide hole and press
them slightly.
Please get rid of the residue in
the residue cup.
Note: do not put your finger or other
things into the guide hole. Otherwise
it will be dangerous.
Troubleshooting
Trouble
Possible
Cause
Check
Motor
does not
operate
Safety lock
is not con-
nected
Reassemble
the cup and
connect with
the base
correctly.
Motor
overheat
or smell
not good
Too much
food or
working
time to long
Reduce the
food and run
it again after
the unit cool
down
Maintenance
1.
Avoid any bumping of the appliance,
otherwise it will be deformed or
broken.
2.
After usage, please clean the ap-
pliance and wipe the parts with a dry
cloth and store it in dry and windy
place.
Cleaning and maintenance
1. The appliance is easier to clean if you
do so immediately after use.
2. Do not use abrasive cleaning agents,
scourers, acetone, alcohol etc. to clean
the appliance.
3. Clean these parts with the cleaning
brush in warm water with some wash-
ing-up liquid and rinse them under the
tap.
Electric Circuit Diagram
Specification
Power:
350 W
Working voltage
220-230 V
