39
Audio Adjustment
Note:
• If you make adjustments when a curve other than “CUSTOM” is selected, the newly adjusted curve
will replace the previous adjusted curve. Then a new curve with “CUSTOM” appears on the display
while selecting the equalizer curve. (Refer to page 37.)
Equalizer Curve Fine Adjustment
You can adjust the center frequency and the Q factor (curve characteristics) of each cur-
rently selected curve band (EQ-Low/Mid/High). Adjusted equalizer curve settings are
memorized in “CUSTOM”.
1. Press the AUDIO button for 2 seconds to select Equalizer Curve Fine
Adjustment.
Note:
• If you make adjustments when a curve other than “CUSTOM” is selected, the newly adjusted curve
will replace the previous adjusted curve. Then a new curve with “CUSTOM” appears on the display
while selecting the equalizer curve. (Refer to page 37.)
4. Select the desired Q factor
with the
5/∞ buttons.
2N
+= 1N += 1W += 2W
3. Select the desired frequency
with the
2/3 buttons.
Low: 40
+= 80 += 100 += 160 (Hz)
Mid: 200
+= 500 += 1k += 2k (Hz)
High: 3.15k
+= 8k += 10k += 12.5k (Hz)
2. Press the AUDIO button to
select the desired band for
adjustment.
“ ”
3. Boost or attenuate the selected
band with the
5/∞ buttons.
The display shows “+6” – “–6”.
Level (dB)
Center frequency Frequency (Hz)
Q=2N Q=2W
