Front panel controls
Main unit
©Cassette lid
©Cassette open button { ± OPEN)..........................................17
@AC supply indicator (AC IN)
This indicator lights when the unit is connected to the AC
mains supply.
(3)Standby/on switch (o/l)
Press to switch the unit from on to standby mode or vice
versa. In standby mode, the unit is still consuming a
small amount of power.
® Aux button (AUX)................................................................. 21
® CD skip/search, tape fast-forward/rewind/TPS, tune/
preset channel select, time adjust buttons
(►►I A/FF, V/REW)............................ 9, 11, 12,16, 18, 23
@CD check button (CD CHECK)............................................ 13
®CD trays
©Tape indicator
This indicator changes in the following manner:
@ Orange (when no cassette is inserted.)
® Green (when cassette is inserted.)
© Red (when in recording mode.)
©Display
©Recording start/pause button (•/!! REC)............................. 19
©Super sound EQ button (S.SOUND EQ)..............................21
©Volume control (VOLUME DOWN, UP).................... 9,12,17
©CD tray open/close button (± OPEN/CLOSE)..................... 12
©CD change button ( ± CD CHANGE)........... ..................... 13
©Headphone jack (PHONES)................................................. 21
©Stop/program clear and demonstration button
(STOP ■, -DEMO)........................................... 12, 16, 17, 22
©Tuner/band select button (TUNER/BAND)..........................10
©Cassette play button (TAPE ►)........................................... 17
©CD play/pause button (CD ►/!!).......................................... 12
©Disc direct play buttons (CD 1~CD 5)................................. 12
