SUCTION POWER CONTROL (REMOTE CONTROL MODEL ONLY)
Your cleaner has variable electronic suction control to give you greater versatility.
Select the most suitable position according to cleaning needs.
The suction capacity can be regulated Steplessly by moving the slide to the desired
position
mm
JA JUHTNUPUD ( AINULT KAUGJUHTMISEGA VOIMSUSE REGULEERIMISE MUDEUTEL}
imamisvoimsust Saab uhtlaselt reguieerida, lOkates regulaator soovitud asendile.
WAX
I
SLIDE THE PART “A" IN THE STOP POSITION
Vacuum cleaner switches off (stand by mode)
SLIDE THE PART “A" TOWARDS MAX
Suction capacity increases steplessly up to MAX.
DUST INDICATOR
You may continue cleaning until the dust indicator changes and displays a red colour. This
means the dust bag is full and needs to be replaced.
If the indicator suddenly displays red and the cleaner loses suction power while in use, turn
your cleaner off and check whether the hose, pipe or nozzle is clogged.
When you check bag status by indicator, set motor power on maximum position.
DUST BAG REMOVAL(DUST COVER)
E : Hose must be disconnected before changing bag,
Replace the dust bag as soon as it is full.
1. To open the dust cover of the dust bag
compartment, lift the cover upward.
2. Remove the dust bag from the cleaner.
3. Dispose of the full bag. Insert the
cardboard bag oollar of the dust bag as
tar as
It
can go on the suction inlet along
the slide guide. Press down the locker.
Position the dust bag so that no part of
the bag is pinched.
4. Press the front of dust cover down lightly
until it re-locks.
LOCKER
