6
LOCATION OF CONTROLS
Figure A
1. Handset.
2. Handset indicator light – lights up when your phone goes on-
line (incoming / outgoing calls) as well as when the handset
rechargeable battery needs to be recharged
3. PHONE ( ) button – use this button to answer a call, start talking
and finish a phone call
4. SEC/HOLD button – turns off the microphone during a call or
transfers a call to the base unit or the other handset (only Twin
XA2020)
5. R (Recall) button – can be used if your telephone company
supports this feature.
6. LNR/Pause button – use this button to redial the last dialed
number or insert a pause while dialing.
7. Volume/Ringer
button - to control the handset earpiece
volume or to select a ringer tone.
8. ÌÅÌ button – saves a phone number to the phone memory.
9. Dialing buttons.
10.CH button – use to change a channel during a call if noise
interferes with the conversation
11.Handset telescopic antenna – to use during phone call for
eliminating noise
Figure B
12.Indicator light – lights up in the Speakerphone mode.
13.Base unit.
14.SPEAKERPHONE button – turns on the Speakerphone mode.
15.CHARGE/In-use indicator– lights up during battery charging
or when your phone goes on-line.
16.PAGE ))) button – to use for locating the handset of for
transferring a call
17.
control - to control the speakerphone volume.
18.Base unit telescopic antenna – to use during phone call for
eliminating noise
Figure C
19.Rechargeable battery – a Ni-Cd battery, which is used for
supplying power to the handset.
20.Battery compartment – for installing the rechargeable battery.
21.Battery compartment cover – to fix the rechargeable battery
in its compartment.
22.Handset belt clip –use it if you want to wear the handset on your
belt.
23.Belt clip slot – to fix the belt clip on the handset.
Figure D
24.Base unit AC adapter jack – to connect the AC adapter to the
base unit.
