8
GB
English
TECHNICAL DATA
Oscillating sander
FDS 140
Rated input ....................................................260 W
No-load speed .............................................14000 min
-1
Orbital travel diameter ....................................1,6 mm
Dimensions of grinding plate
..................
110 x 105
mm
110 / 110
mm
Weight according EPTA-Procedure 01/2003
.....
1,5
kg............
1,6
kg
Noise/Vibration Information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K=3dB(A))
...................76,5 dB(A) ... 82,0 dB(A)
Sound power level (K=3dB(A))
........................87,5 dB(A) ... 93,0 dB(A)
Wear ear protectors!
Total vibration values (vector sum in the three axes) determined
according to EN 60745.
Vibration emission value a
h
................................4,8 m/s
2
..... 10,0 m/s
2
Uncertainty K
.......................................................1,5 m/s
2
....... 1,5 m/s
2
WARNING
The vibration emission level given in this information sheet has been
measured in accordance with a standardised test given in EN 60745
and may be used to compare one tool with another. It may be used
for a preliminary assessment of exposure.
The declared vibration emission level represents the main applica-
tions of the tool. However if the tool is used for different applications,
with different accessories or poorly maintained, the vibration
emission may differ. This may significantly increase the exposure level
over the total working period.
An estimation of the level of exposure to vibration should also take
into account the times when the tool is switched off or when it is
running but not actually doing the job. This may significantly reduce
the exposure level over the total working period.
Identify additional safety measures to protect the operator from the
effects of vibration such as: maintain the tool and the accessories,
keep the hands warm, organisation of work patterns.
WARNING! Read all safety warnings and all instruc-
tions, including those given in the accompanying brochure.
Failure to follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Wear ear protectors. Exposure to noise can cause hearing loss.
Appliances used at many different locations including open air should be
connected via a residual current device (FI, RCD, PRCD) of 30mA or less.
Always wear goggles when using the machine. It is recommended to
wear gloves, sturdy non slipping shoes and apron.
Before doing any work on the machine, pull the plug out of the socket.
Only plug-in when machine is switched off.
Keep mains lead clear from working range of the machine. Always
lead the cable away behind you.
Before use check machine, cable, and plug for any damages or material
fatigue. Repairs should only be carried out by authorised Service Agents.
The dust produced when using this tool may be harmful to health. Do
not inhale the dust. Use a dust absorption system and wear a suitable
dust protection mask. Remove deposited dust thoroughly, e.g. with a
vacuum cleaner.
Do not use machines on any material containing asbestos.
This machine is suitable only for dry sanding.
SPECIFIED CONDITIONS OF USE
The orbital sander can be used for sanding wood, plastics and metal.
Do not use this product in any other way as stated for normal use.
MAINS CONNECTION
Connect only to single-phase AC current and only to the
system voltage indicated on the rating plate. It is also possible
to connect to sockets without an earthing contact as the design
conforms to safety class II.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is in confor-
mity with the following standards or standardized documents.
EN 60745-1:2009 + A11:2010
EN 60745-2-4:2009 + A11:2011
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
EN 61000-3-2:2006 + A1:2009 + A2:2009
EN 61000-3-3:2008
in accordance with the regulations 2011/65/EU (RoHs), 2006/42/EC,
2004/108/EC
Rainer Kumpf
Director Product Development
Authorized to compile the technical file
Winnenden, 2012-09-05
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and spare parts. Should components need to
be replaced which have not been described, please contact one of our
AEG service agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label and
order the drawing at your local service agents or directly at: AEG Elec-
tric Tools GmbH, Max-Eyth-Straße 10, D-71364 Winnenden, Germany.
SYMBOLS
Please read the instructions carefully before starting the
machine.
CAUTION! WARNING! DANGER!
Always disconnect the plug from the socket before
carrying out any work on the machine.
Accessory - Not included in standard equipment, availa-
ble as an accessory.
Do not dispose of electric tools together with household
waste material! In observance of European Directive
2002/96/EC on waste electrical and electronic equipment
and its implementation in accordance with national law,
electric tools that have reached the end of their life must
be collected separately and returned to an environmen-
tally compatible recycling facility.
Class II construction, tool in which protection against
electric shock does not rely on basic insulation only, but
in which additional safety precautions, such as double
insulation or reinforced insulation, are provided.
