Maintenance – Инструкция по эксплуатации Panasonic ES-RF31
Страница 7
7
English
Cleaningwiththebrush
Clean the inner blades [C] using the short
brush by moving it in direction (A).
Clean the system outer foil [B2], the shaver
body and the trimmer [D:] using the long
brush.
Do not move the short brush in direction (B)
as it will damage the inner blades [C] and
affect their sharpness.
Do not use the short brush to clean the outer
foils.
•
•
(A)
(B)
Maintenance
Replacingthesystemouterfoilandtheinnerblades
system outer foil
once every year
inner blade
once every two years
Replacingthesystemouterfoil
1. Press the foil frame release buttons [D4]
and lift the outer foil section [B] upwards.
. Press the system outer foil release buttons
[B3] and pull down the system outer foil
[B2].
1
3. Insert the system outer foil [B2] until it clicks
as illustrated.
Always attach the system outer foil [B2] in
proper direction.
Always insert the system outer foil [B2] to
the foil frame [B1] when attaching to the
shaver.
•
•
3
2
Replacingtheinnerblades
1. Press the foil frame release buttons [D4]
and lift the outer foil section [B] upwards.
1
. Remove the inner blades [C] one at a time.
Do not touch the edges (metal parts) of the
inner blades [C] to prevent injury to your
hand.
3. Insert the inner blades [C] one at a time until
they click.
•
2 3
