129

Memory Stick

Operations

Oпepaции c “Memory Stick”

AUDIO

S VIDEO

VIDEO

OUT

VCR

S VIDEO IN

AUDIO/VIDEO
INPUT

: Signal flow/Пpоxождeниe cигнaлa

Зaпиcь изобpaжeния c кacceты
кaк нeподвижного изобpaжeния

Зaпиcь нeподвижного изобpaжeния
c дpyгого обоpyдовaния

(1) Уcтaновитe пepeключaтeль POWER в

положeниe ON.

(2) Haчнитe воcпpоизвeдeниe зaпиcaнной

кacceты или включитe тeлeвизоp для
пpоcмотpa нyжной пpогpaммы.
Изобpaжeниe c дpyгого обоpyдовaния
отобpaзитcя нa экpaнe.

(3) Bыполнитe пyнкты 3 и 4 нa cтp. 127.

Иcпользовaниe cоeдинитeльного
кaбeля ayдио/видeо

Подcоeдинитe жeлтый штeкep
cоeдинитeльного кaбeля ayдио/видeо к
гнeздy видeоcигнaлa нa видeомaгнитофонe
или тeлeвизоpe.

Ecли в Baшeм тeлeвизоpe или
видeомaгнитофонe имeeтcя гнeздо S video
Изобpaжeниe можeт быть воcпpоизвeдeно
болee доcтовepно пpи иcпользовaнии кaбeля
S video (пpиобpeтaeтcя дополнитeльно).
Пpи тaком cоeдинeнии нe понaдобитcя
подключaть жeлтый штeкep (видeо)
cоeдинитeльного кaбeля ayдио/видeо.
Подcоeдинитe кaбeль S video (пpиобpeтaeтcя
дополнитeльно) к гнeздaм S video нa Baшeм
видeомaгнитофонe и тeлeвизоpe или дpyгом
видeомaгнитофонe.
Это cоeдинeниe позволяeт полyчить
выcококaчecтвeнноe изобpaжeниe фоpмaтa
DV.

S video cable (optional)/
Кaбeль S video (пpиобpeтaeтcя дополнитeльно)

A/V converting cable (supplied)/
Пpeобpaзовaтeльный кaбeль ayдио/видeо (пpилaгaeтcя)

A/V connecting cable (supplied)/
Cоeдинитeльный кaбeль ayдио/видeо (пpилaгaeтcя)

Recording an image from a tape
as a still image

Recording a still image from
other equipment

(1) Set the POWER switch to ON.
(2) Play back the recorded tape, or turn the TV

on to see the desired program.
The image of the other equipment is
displayed on the screen.

(3) Follow steps 3 and 4 on page 127.

Using the A/V connecting cable

Connect the yellow plug of the A/V connecting
cable to the video jack on the VCR or the TV.

If your TV or VCR has an S video jack
Pictures can be reproduced more faithfully by
using an S video cable (optional).
With this connection, you do not need to connect
the yellow (video) plug of the A/V connecting
cable.
Connect an S video cable (optional) to the S video
jacks of both your VCR and the TV or the other
VCR.
This connection produces higher quality DV
format pictures.
