English - 5

Viewing the Control Panel

TV Controller is a multi directional button that helps navigate without remote control.

Some functions which require a PIN code may not be available.

The product colour and shape may vary depending on the model.

The TV's Controller, a small joy stick like button on the bottom left side of the TV, lets you control the
TV without the remote control.

m

R

P

Down(Front)

Function menu

TV Controller

Left

Right

Up(Rear)

Remote control sensor

Follow these instructions facing the front of your TV.

When selecting the function by moving the controller to the forwards/backwards/left/right directions,
be sure not to press the controller. If you press it first, you cannot operate it to move the forwards/
backwards/left/right directions.

Power on

Turn the TV on by pressing the Controller when the TV is in standby mode.

Adjusting the volume

Adjusts the volume by moving the controller from side to side when the
power is on.

Selecting a channel

Select a channel by moving the Controller backwards and forwards when
the power is on.

Using the function menu

To view and use the Function menu, press and release the Controller
when the power is on. To close the Function menu, press and release the
Controller again.

Selecting the MENU (

m

)

With the Function menu visible, select the MENU (

m

) by moving the

Controller to the left. The OSD (On Screen Display) Menu appears. Select
an option by moving the Controller to the right. Move the Controller to the
right or left, or backwards and forwards to make additional selections. To
change a parameter, select it, and then press the Controller.

Selecting the SMART HUB
(

)

With the Function menu visible, select SMART HUB (

) by moving the

Controller backwards. The SMART HUB main screen appears. Select an
application by moving the Controller, and then pressing the Controller.

Selecting the Source (

s

)

With the Function menu visible, open the Source (

s

) by pushing the

Controller to the right. The Source screen appears. To select a Source,
move the Controller back and forth. When the source you want is
highlighted, press the Controller.

Power off (

P

)

With the Function menu visible, select Power off (

P

) by pulling the

Controller forwards, and then press the Controller.

To close the Menu, Smart Hub, or Source, press the Controller for more than 1 second.

Standby mode

Your TV enters Standby mode when you turn it off and continues to consume a small amount of electric
power. To be safe and to decrease power consumption, do not leave your TV in standby mode for long
periods of time (when you are away on vacation, for example). It is best to unplug the power cord.

[PE550-RU]BN68-04057P-00L03.indb 5

2012-05-08 �� 1:35:21
