English - 1
White Balance
You can adjust the colour temperature for more natural picture colours.
R-Offset / G-Offset / B-Offset / R-Gain / G-Gain / B-Gain: Changing the adjustment value will refresh the adjusted screen.
Reset: Resets the default white balance.
Flesh Tone
You can emphasize the pink flesh tone in the picture.
Changing the adjustment value will refresh the adjusted screen.
Ed�e En�ancement → ��� / �n
→ ��� / �n
Off / On
You can emphasize object boundaries in the picture.
xvYCC → ��� / �n
Setting the xvYCC mode to on increases detail and colour space when watching
movies from an external device (i.e. DVD player).
xvYCC is available when the picture mode is set to Movie, and the external input is
set to
HDMI or Component mode.
If
xvYCC function is active, PIP cannot be selected.
Picture Options
You can customize the additional picture settings to suit your preference.
In
PC mode, you can only make changes to the Colour Tone, Size and Screen
Burn Protection from among the items in Picture Options.
Colour Tone → Cool / Normal / �arm�� / �arm�� / �arm3
→ Cool / Normal / �arm�� / �arm�� / �arm3
Cool / Normal / Warm1 / Warm / Warm3
You can select the most comfortable colour tone to your eyes.
The adjusted values are stored according to the selected
Picture mode.
Warm1, Warm, or Warm3 is only activated when the picture mode is Movie.
Size → Auto �ide / ��6:9 / �ide Zoom / Zoom / 4:3 / Screen Fit
You can select the picture size which best corresponds to your viewing requirements.
Auto Wide: Sets the picture in Auto Wide format.
16:: Sets the picture to the 16:9 aspect ratio.
�ide Zoom: Select this menu to view 4:3 aspect ratio pictures over a 16:9 aspect ratio TV by stretching the 4:3 picture
vertically.
Zoom: Stretches the 16:9 aspect ratio picture vertically.
4:3: Sets the picture to the 4:3 aspect ratio.
Screen Fit: Displays the full native HD signal that cannot be viewed using a normal TV.
Alternately, you can press the
P.SIZE button on the remote control repeatedly to
change the picture size.
Depending on the input source, the picture size options may vary.
The items available may differ depending on the selected mode.
In
PC Mode, only 16:9 and 4:3 mode can be adjusted.
Settings can be adjusted and stored for each external device you have connected to an input of the TV.
Temporary image retention may occur when viewing a static image on the set for more than two hours.
�ide Zoom: Press the ► button to select Position, then press the ENTERE button.
Press the ▲ or ▼ button to move the screen up / down. Then press the
ENTERE button.
Zoom: Press the ► button to select Position, then press the ENTERE button. Press the ▲ or ▼ button to move the
picture up and down. Then press the
ENTERE button. Press the ► button to select Size, then press the ENTERE button.
Press the ▲ or ▼ button to magnify or reduce the picture size in the vertical direction. Then press the
ENTERE button.
After selecting
Screen Fit in HDMI (1080i / 1080p) or Component (1080i / 1080p) mode: Select Position by pressing
the ◄ or ►button. Use the ▲, ▼, ◄ or ► button to move the picture.
Reset: Press the ◄ or ► button to select Reset, then press the ENTERE button. You can initialize the setting.
If you use the
Screen Fit function with HDMI 720p input, 1 line will be cut at the top, bottom, left and right as in the overscan
function.
Screen Mode → ��6:9 / �ide Zoom / Zoom / 4:3
When setting the picture size to
Auto Wide in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS
(Wide Screen Service) image or nothing. Each individual European country requires different picture size so this function is
intended for users to select it.
This function is available in
Auto Wide mode.
This function is not available in
PC, Component or HDMI mode.
•
•
N
❑
N
N
❑
N
N
N
•
•
•
•
•
•
O
N
N
N
N
N
N
N
N
N
N
N
N
Continued...
Tint (G/R)
: G50/R50
Advanced Settings
Picture Options
►
Picture Reset
