20
English
Basic Features
Picture In Picture (
¦
PIP)
PIP
t
Watches simultaneously the TV tuner and one external video
source. PIP (Picture-in-Picture) does not function in the same
mode.
NOTE
✎
If you turn the TV off while watching in
x
PIP mode, the
PIP window will disappear.
You may notice that the picture in the PIP window
x
becomes slightly unnatural when you use the main
screen to view a game or karaoke.
PIP settings
x
Main picture
Sub picture
Component, HDMI1/DVI,
HDMI2, HDMI3, HDMI4,
PC
TV
PIP (Off / On)
■
: Activate or deactivate the PIP function.
Channel
■
: Select the channel for the sub-screen.
Size (
■
Х / Г): Select a size for the sub-picture.
Position (
■
à / – / — / œ): Select a position for the
sub-picture.
Sound Select (Main / Sub)
■
: You can choose the
desired sound (Main / Sub) in PIP mode.
Support Menu
Self Diagnosis
Self Diagnostic might take few seconds, this is part of the
normal operation of the TV.
Picture Test (Yes / No)
■
: Use to check for picture
problems and if the problem continues to occur check
the colour pattern.
Sound Test (Yes / No)
■
: Use the built-in melody sound to
check for sound problems.
If you hear no sound from the TV’s speakers,
✎
before performing the sound test, make sure
Speaker Select is set to TV speaker in the
Sound menu.
The melody will be heard during the test even if
✎
Speaker Select is set to External Speaker or the
sound is muted by pressing the
MUTE
button.
Signal Information
■
: (digital channels only) HDTV
channel’s reception quality is either perfect or the
channels are unavailable. Adjust your antenna to
increase signal strength.
Troubleshooting
■
: If the TV seems to have a problem,
refer to this description.
If none of these troubleshooting tips apply, contact
✎
the Samsung customer service centre.
Software Upgrade
Software Upgrade can be performed via a broadcasting
signal or by downloading the latest firmware from samsung.
com to a USB memory device.
Current Version the software already installed in the TV.
Software is represented as “Year/Month/Day_Version”.
✎
Installing the Latsted Version
By
■
USB: Insert a
USB drive containing
the firmware upgrade
file, downloaded from
www.samsung.com,
into the TV. Please
be careful not to
disconnect the power
or remove the USB
drive until upgrades
are complete. The TV
will be turned off and on automatically after completing
the firmware upgrade. When software is upgraded,
video and audio settings you have made will return
to their default settings. We advise you to write down
your settings so that you can easily reset them after the
upgrade.
or
TV Side Panel
TV Rear Panel
USB Drive
Software Upgrade
Current Version
2010/01/18_000001
U Move E Enter R Return
By USB
►
By Online
By Channel
Standby Mode Upgrade : Off
Alternative Software ----/--/--/--_------
