English - 60
Home Network Centre
About the Home Network Centre
The Home Network Centre connects the TV and mobile phones through a network. You can view call arrivals, text message contents,
and schedules set on the mobile phone on the TV using the Home Network Centre. In addition, you can play the media contents saved
on the mobile phones such as videos, photos and music by controlling them onto the TV via the network.
If the device supports DLNA DMC (Digital Media Controller) function, Home Network Centre function is available. N
This function is for compatibility with Samsung mobile phone which will be released later on. For more information, visit www. N
samsung.com or contact Samsung call center. Other models will be added in the future. The mobile device may need additional
software installation. For details, refer to each user’s guide.
Connecting to the Home Network Centre
❑
For more information about the network settings, refer to ‘Network Setup’.
Connecting to a Wi-Fi Ad-hoc network
„
1. Connect the ‘Samsung Wireless LAN Adapter’ to the USB1(HDD) or USB2 port of the TV.
2. For more information on how to configure Ad-hoc network, refer to ‘Setting the Network’.
For information on configuring the mobile phone’s network settings, refer to the mobile phone manual. N
3. Set up the IP address, SSID and password for the mobile phone in the Ad-hoc Settings of the mobile phone using the Network
Name (SSID) and Security Key (password) displayed on the TV.
Connecting through a wire / wireless IP sharer
„
1. Connect the LAN port of the TV and the Wire/Wireless IP sharer using the LAN cable or connect the USB1(HDD) or USB2 port
of the TV and the ‘Samsung Wireless LAN Adapter’.
For the procedures to set up the wire/wireless sharer and the mobile phone, refer to the manual of the corresponding device. N
Home Network Centre
TV Side Panel
Samsung Wireless
LAN Adapter
Mobile phone
Samsung Wireless
LAN Adapter
Wire/Wireless IP sharer
TV Side Panel
Mobile phone
or
or
LAN Cable
Samsung Wireless
LAN Adapter
TV Side Panel Mobile phone
or
LAN Cable
Wire/Wireless IP sharer
