Initial Pairing
TV STB BD
RETURN VOICE NUMBER
TV STB BD
RETURN VOICE NUMBER
<Pairing complete> <Connecting>
30cm ~ 4m
IR receiver
• Smart Touch Control
After you have run the Initial Setup on your TV, you should connect your Smart Touch Control to your TV.
1. Turn the TV on by pressing the P button on.
2. The connection icons appear on the bottom left of the screen, and the TV connects to your Smart Touch Control automatically.
✎ If you want to perform the pairing process again, press the reset button in the centre of the back cover using a pin or the tip of an unbent
paper clip. The Smart Touch Control will be initialized.
• Smart Touch Control PAIRING Reset button
Calibrating the Touch Pad
To calibrate the Touch Pad on the Smart Touch Control, follow these steps:
1. Press the NUMBERš button for 3 seconds. The calibration starts.
2. When done, all the LEDs on the top of the Smart Touch Control blink twice simultaneously.
✎ While calibrating, don't touch the Touch Pad.
✎ If the Touch Pad looses accuracy, re-calibrate the Touch Pad by repeating Steps 1 and 2.
Using the Touch Pad
To display the shortcut functions list on the bottom of the screen, press the ‹ button at the bottom of the Touch Pad. This list include Menu,
Source, CH List, 3D and other functions.
To display the colour and playing control functions on the top of the screen, press the
button on the top of the Touch Pad.
RETURN VOICE NUMBER
To Move the Highlight: Rest your finger on the Touch Pad, and then slide it from one side to the other, from top
to bottom, or bottom to top.
✎ To move the Highlight continuously, flick your finger across the Touch Pad from right to left, left to right,
top to bottom, or bottom to top.
RETURN VOICE NUMBER
To Select an item: Press the Touch Pad.
English - 7
