English - 27
Serial Cable(1P to 1P)(Not supplied)
Rear Panel
Auto Wall-Mount
Wall- mount adjustment (Sold separately)
(PS-50P96FDR)
Once the wall mount is installed, the position of your TV can be easily adjustable.
Entering the menu
1 Press the MENU button to display the menu.
Press the ▲ or ▼ button to select
Setup, then press the
ENTER/OK button.
2 Press the ▲ or ▼ button to select Wall-Mount Adjustment,
then press the
ENTER/OK button.
3 Adjust to the desired position using the ▲/▼/◄/► buttons.
Press the
EXIT button to exit.
➢
If you press an arrow button when no OSD is displayed on the
TV screen, the Adjustment screen appears.
➢
When you turn the power off, your TV moves to the initial
installation position.When you turn the power on, your TV
moves to the last remembered position you adjusted.
Using the remote Control Buttons
Button
Operations
Wall-mount
angle
adjustment
Tilt Up, Tilt Down, Move
right, Move left
Reset
Moves to the initial
installation position
(Red) (Green) (Yellow)
Remembering
the position and
moving to the
remembered
position
Remembers 3 positions
with the Red, Green and
Yellow buttons.
Moves to the remembered
position using these 3
colour buttons.
➢
For installation, refer to the Installation Manual provided.
➢
For product installation and the installation and moving of the wall mount, make sure to consult a
specialized installation company.
➢
This installation manual is to be used when attaching the wall mount to a wall. When attaching to
other building materials, please contact your nearest dealer.
Move
Enter
Return
More
Wall-Mount Adjustment
Energy Saving
:
Off
HDMI Black Level : Normal
PIP
Screen Burn Protection
Setup
T V
Wall-Mount Adjustment
Position1
Adjust
Centre
Exit
INFO
Position
1
2
3
