English -
Auto Wall-Mount Adjustment (Sold separately) (depending on the model)
Once the auto wall mount is installed, your TV’s position can be easily adjusted.
Entering the menu
1. Press the ▲, ▼, ◄ or ► button on your remote control.
The Wall Mount Adjustment screen is displayed.
If the Auto Wall-Mount screen is not displayed when clicking on a direction
button while watching your TV, use the menu to display that screen.
Press the MENU button to display the menu. Press the ▲ or ▼ button to
select “Setup”, then press the ENTERE button.
Press the ▲ or ▼ button to select “Wall-Mount Adjustment”, then press
the ENTERE button.
N
N
-
-
Remembering the Position
2. Adjust to the desired position using the ▲,▼,◄,► buttons.
If you press an arrow button when no OSD is displayed on the TV screen,
the Adjustment screen appears.
Press the INFO button to reset. Press the ◄ or ► button to select “Yes”,
then press the ENTERE button. The position is initialized to the default
setting.
3. Press the blue button. Press the ▲ and ▼ buttons to select a save mode from
either Position 1, Position 2 or Position 3 in order to save the current position.
To not save the current position, press the RETURN button.
When selecting a save mode, you cannot use the Colour buttons.
4. Press the ENTERE button to save.
When Position1 is selected, the message “Current position saved as Position1” is displayed.
5. Press the ENTERE button.
The saved Position appears on the left side of the OSD.
Moving to the remembered position
1. Complete Step 1 of “Entering the menu”.
2. Pressing a Colour (Red, Green, Yellow) button moves the auto wall mount to the
saved position.
You can move the wall mount to one of the 3 pre-set positions by pressing
the Red (Position 1), Green (Position 2) or Yellow (Position 3) buttons.
If you adjust the Position after moving to a pre-set position, the position
display will disappear.
For installation, refer to the Installation Manual provided with the wall mount.
For product installation and the installation and moving of the wall mount, make sure to consult a specialized installation
company.
This installation manual is to be used when attaching the wall mount to a wall. When attaching to other building materials,
please contact your nearest dealer.
The auto wall mount will not work when Anynet+ or WISELINK Pro is operating.
46 model are not compatible with the older wall mount model (WMN5090A).
N
N
N
O
N
N
N
N
N
N
N
N
N
Setup
Preference
Digital Text
: Enable
Wall-Mount Adjustment ►
Melody : Off
Entertainment : Off
Energy Saving : Off
PIP
Software Upgrade
Common Interface
Wall-Mount Adjustment
Position  2
Adjust Save Centre
Save
Select a mode to save.
Move Enter Return
Position
Position2
Position
TV Rear Panel
Auto Wall-Mount
SERVICE Cable (Not supplied)
