Samsung PS51D6900DS - Инструкция (Страница 9)

English - 9
Using a Component (up to 1080p) or an Audio/Video (480i only) and a Scart Cable
✎
In Ext. mode, DTV Out supports MPEG SD Video and Audio only.
✎ When connecting to AV IN , the colour of the AV IN [VIDEO] jack (green) will not match the video cable
(yellow).
✎ To obtain the best picture quality, the Component connection is recommended over the A/V
connection.
EXT (RGB)
ANT 2 IN
(SATELLITE)
AUDIO OUT
R-AUDIO-L
VIDEO OUT
AUDIO OUT
R-AUDIO-L
P R P B Y
COMPONENT OUT
EXT
R
R
B
G
W
R
B
G
R
W
R
W
R
W
Y
Y
Component connection
AV connection
SCART connection
