English -
Using the Media Play Function
This function enables you to view and listen to photo, music and movie files saved on a USB Mass Storage Class (MSC) device.
Entering the Media Play Menu
1. Press the MENU button. Press the ▲ or ▼ button to select Application, then
press the
ENTER
E
button.
. Press the ▲ or ▼ button to select Media Play (USB), then press the ENTER
E
button.
The
Media Play menu is displayed.
Press the
SOURCE button on the remote control repeatedly to select USB,
then press the
ENTER
E
button.
Press the
MEDIA.P button on the remote control to display the Media Play
menu.
3. Press the Red button, then press the ▲ or ▼ button to select the corresponding
USB Memory Device (i.e. if connected through a hub). Press the
ENTER
E
button.
This function differs depending on the USB Memory Device/ DLNA device
connected to TV.
The selected USB device name appears at the bottom left of the screen.
4. Press the ◄ or ► button to select an icon (Photo, Music, Setup), then press
the
ENTER
E
button.
To exit
Media Play mode, press the MEDIA.P button on the remote control.
In this mode, you can enjoy movie clips contained on a Game, but you cannot play the Game itself.
Removing a USB Memory Device Safely
You can remove the device safely from the TV.
1. Press the TOOLS button in the Media Play file list screen, or while a Slide Show
or music file is being played.
. Press the ▲ or ▼ button to select Remove Safely, then press the ENTER
E
button.
3. Remove the USB device from the TV.
Screen Display
1. Currently selected file: The currently selected file is highlighted.
. View Groups: The sorting group including the currently selected photo is highlighted.
One group involves the nine photos.
3. Current Device: Shows the currently selected device name.
4. Item Selection Information: Shows the number of photos that are selected by pressing the Yellow button.
5. Help Items
Red (
Device) button: Selects a connected device.
Yellow (
Select) button: Selects file from the file list. Selected files are marked with a symbol c. Press the yellow button again
to cancel a file selection.
(Tools) button: Displays the option menus. (The tools menu changes according to the current status.)
R
(Return) button: Return to previous menu.
•
•
•
•
❑
N
O
O
N
N
N
N
❑
❑
N
Media Play
Music
Setup
USB : USB name
148.48MB/995.00MB Free
R
Return
USB Device
4/6
IMG_0349.
JPG
▶
▶
IMG_0346.
JPG
1
IMG_0345.
JPG
1
Slide Show
Play Current Group
Information
Remove Safely
USB
USB Device
Select
T
Tools R Upper Folder
IMG_0343.
JPG
▶
▶
IMG_03496.
JPG
IMG_03496.
JPG
1/67
▶
▶
◀
IMG_03496.
JPG
1
3
1File(s) Selected
4
5
USB Device
Select
T
Tools R Upper Folder
▶
▶
1
1
USB
