Инструкция по эксплуатации Samsung UE46D5000PW
Страница 6
English - 6
Connecting to an Antenna
When the TV is initially powered on, basic settings proceed automatically.
✎
Preset: Connecting the mains and antenna.
Plug & Play (Initial Setup)
When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the
POWER
P button. Plug & Play is available only when the Input source is set to TV.
✎
To return to the previous step, press the Red button.
1
Selecting a language
Press the
▲ or ▼ button, then press the
ENTER
E button.
Select the desired OSD (On Screen Display) language.
P
POWER
2
Selecting Store Demo or
Home Use
Press the
◄ or ► button, then press the
ENTER
E button.
Select the Home Use mode. Store Demo mode is for retail environments.
To return the unit’s settings from Store Demo to Home Use (standard):
Press the volume button on the TV. When the OSD volume is displayed,
press and hold
MENU
for 5 sec.
Store Demo is only for shop display. If you select it, several functions are not
able to use. Please select Home Use when you watch at home.
3
Selecting a country
Press the
▲ or ▼ button, then press the
ENTER
E button.
Select the appropriate country.
✎
After selecting the country in the Country menu, some models may proceed with an
additional option to setup the pin number.
✎
When you input the PIN number, 0-0-0-0 is not available.
✎
The option may differ depending on country.
4
Setting the Clock Mode
Set the Clock Mode automatically or manually.
Auto: Select the time zone (depending on the country) where you are located.
Manual: Allows you to manually set the current date and time.
5
Selecting an antenna
Press the
▲ or ▼ button, then press the
ENTER
E button.
Select the desired broadcasting signal.
6
Selecting a channel
Press the
▲ or ▼ button, then press the
ENTER
E button.
Select the channel source to memorise. When setting the antenna source to Cable, a step
appears allowing you to assign numerical values (channel frequencies) to the channels. For more
information, refer to Channel
→ Auto Tuning.
Press the
ENTER
E button at any time to interrupt the memorisation process.
7
Enjoy your TV.
Select the Watch TV. Press the
ENTER
E button.
✎
If you select the Network Settings, set the network. For more information, refer to
“Network menu” in the e-Manual.
If You Want to Reset This Feature...
Select System - Plug & Play (Initial Setup). Enter your 4 digit PIN number. The default PIN number is “0-0-0-0”. If you want to
change the PIN number, use the Change PIN function.
You should do Plug & Play (
MENU
→ System) again at home although you did in shop.
✎
If you forget the PIN code, press the remote control buttons in the following sequence in Standby mode, which resets
the PIN to “0-0-0-0”:
MUTE
→ 8 → 2 → 4 →
POWER
(on).
VHF/UHF Antenna
Cable
or
TV Rear Panel
