IDENTIFICATIONS OF PARTS
ASSEMBLING THE VACUUM - CLEANER READY FOR USE
1) Connect the suction hose to the
suction tube.
2) Connect the suction tubes together
(depending on model).
3) Connect the nozzle to the suction tube.
4) Connect the body connector to the
body of the cleaner.
OPTION: Adjusting the telescopic
tube (depending on
model).
▲
Features marked with * may vary according to model.
HANDLE
AIR REGULATOR
TUBE
*
FLOOR NOZZLE
*
RUG/FLOOR SELECTOR
CARRYING
HANDLE
CLAMPER FOR DUST
BAG COMPARTMENT
ON/OFF BUTTON
POWER CON-
TROL SWITCH
*
CORD REWIND BUTTON
DUST-FULL INDICATOR
*
TOOL STORAGE COVER
SUCTION HOSE
BUTTON FOR
SUCTION HOSE
REMOVAL
