10
ENGLISH
Installation Manual for 3D Viewing
TROUBLESHOOTING
3D Mode Troubleshooting
WHEN THIS HAPPENS DO THIS
3D does not work on the
PC y The LG 3D Game-TriDef 3D software must be installed and running before starting a game.
y Be sure to wear your 3D glasses and sit in a comfortable and appropriate position.
y Try adjusting the tilting angle of the display while looking at the 3D image. You may notice that
the image looks clearer and the double overlapping of the image reduces or disappears at a
certain angle.
y Check that the 2D mode is not enabled. Press "Alt+Shift+-" to switch between 2D mode and
3D mode.
y If two or more Cinema 3D TV are connected, to enjoy 3D images, the Cinema 3D TV must
be set as the primary monitor. If the Cinema 3D TV is not set as your primary Cinema 3D TV,
change your PC display settings accordingly.
y 3The screen resolution must be set to 1920 x 1080 for you to enjoy 3D images.
y The LG 3D Game-TriDef 3D software only works on Windows XP (with the latest service
pack and only at 32-bit), Windows Vista (32-bit only) and Windows 7 (32-bit or 64-bit). The
software is not supported on Linux or Mac operating systems.
3D does not work on the
notebook y After connecting the Cinema 3D TV to your laptop, you must set the Cinema 3D TV as
your primary Cinema 3D TV. If it is not possible to set the Cinema 3D TV as the primary
monitor for your laptop or notebook, you can still watch 3D images by disabling the built-
in screen.
y The screen resolution must be set to 1920 x 1080 for you to enjoy 3D images. Make sure
that the resolution is set correctly.
3D does not work on
game consoles
(including X-BOX 360
and PlayStation 3) y For game consoles, including X-BOX 360, and PlayStation 3: Check whether your game
console supports 3D mode. Some earlier versions of PlayStation 3 need to be updated to
enable 3D viewing.
y Check whether your game title supports 3D mode. To do this, please consult the game
developer’s website. Also note that some game titles may require you to download/install
additional patches for 3D support..
y Make sure that the game title is set to run in 3D mode. If your game title supports 3D, it
should include an option or menu for running it in 3D mode.
y For older devices, you may need to manually set the 3D mode of the game to be the
same as the 3D mode of the Cinema 3D TV.
1. Press the 3D button on the
remote control.
2. Press the OK button to enable 3D.
2D s 3D
Side by Side
Top & Bottom
Checker Board
Frame Sequential
1. Select an output
option.
2. Enable 3D check. 3. Select a 3D format.
For example, Cinema 3D TV
For example, with X-BOX 360
3. In the 3D options, select the same output mode as the mode used by your
game console.
Stop watching moving images, and take a rest, if you have any
symptoms of headache, dizziness, or any uncomfortable feelings.
3D Put on 3D glasses.
3D Mode
OK Cancel
Display Your Tv's 3D Format Side by Side
Line Interlaced
Real D
Sensio
Full Checkerboard
Move Enter Exit
To turn on 3D Mode, select this icon.
