+7(495) 797-3311www.qtech.ru
Москва, Новозаводская ул., 18, стр. 1
7
16
GND
ModuleGround
1
17
CML-O
RD-
Receiverinverteddataoutput
18
CML-O
RD+
Receiver non-inverted data output
19
GND
ModuleGround
1
20
VCC2
+1.8V Power Supply
– Not required
21
LVTTL-I
P_Down/RST
Power Down; When high, places the module in the low power stand-by mode and on
the fallingedgeofP_Downinitiates a module reset
Reset; The falling edge initiates a complete reset of the module including the 2-wire
serial interface, equivalent to a power cycle.
22
VCC2
+1.8V Power Supply
– Not required
23
GND
ModuleGround
1
24
PECL-I
RefCLK+
Reference Clock non-inverted input, AC coupled on the host board
– Not required
3
25
PECL-I
RefCLK-
Reference Clock inverted input, AC coupled on the host board
– Not required
3
26
GND
ModuleGround
1
27
GND
ModuleGround
1
28
CML-I
TD-
Transmitterinverteddatainput
29
CML-I
TD+
Transmitter non-inverted data input
30
GND
ModuleGround
1
2.4.
МЕХАНИЧЕСКАЯ СПЕЦИФИКАЦИЯ
